Gulf Coast Racing Group
General Rules:
1. The Rules and/or Regulations set forth herein do not express or imply warranty of safety from publication of or compliance with Rules and/or Regulations. These rules are intended as a guideline for the conduct of GCRG sanctioned Racing Series events, and are in no way a guarantee against injury or death to participants, spectators, or officials.
2. The Rules and/or Regulations will apply to all Gulf Coast Racing Group sanctioned events. The Rules and/or Regulations will also apply to events sanctioned by the GCRG
3. GCRG officials shall have full authority over said sanctioned events, and in the event of any dispute, the head official’s decision will be final.
4. All competitors and cars are subject to inspection by GCRG Technical Inspectors or their representatives at any time during any event.
5. GCRG, and it’s officials and representatives reserve the right to confiscate any suspicious or deemed illegal parts or components.
6. GCRG reserves the right to alter or amend these Rules and/or Regulations in the interest of fair competition, efficient completion of an event, or for safety. All official’s decisions are final.
7. There is NO appeal process in the determination of or application of fines and/or penalties assessed by the series. All official’s decisions are final, and drivers will not be allowed to compete in any sanctioned events until all fines are paid, penalties assessed have been cleared, and/or suspensions have been served.
Safety Rules:
1. Safety is the primary responsibility of the RACER!!
2. SFI-Approved full fire suit (top and bottom) and shoes required. Racing gloves REQUIRED.
3. Snell rated SA2020 or SA2025 full-face helmet required.
4. All current seats must be full containment type constructed of aluminum or approved carbon fiber and must adhere to the general design specifications of SFI 39.2 seat construction standards. Design should include comprehensive head surround, shoulder and torso support system, energy impact foam, and removable head foam.
5. Series recommends the use of a head and neck restraint system, but is not required.
6. All cars must have a fully charged 2 lb. fire extinguisher mounted within reach of the driver. Series recommends a 5 lb. halon system.
7. All cars must have a kill switch within easy reach of the driver, and clearly marked “Off” and “On”.
8. All cars must have a quality fuel cell with roll over valve (check valve) in fuel cell vent.
9. Minimum three (3) inch wide, or two (2) inch if using head and neck restraint, SFI-Approved five point safety belts, mounted securely to the roll cage. Belts cannot be used past their expiration date or two (2) years past their date of manufacture.
10. Any pre-race technical/safety inspection and car or equipment is deemed unsafe by officials will result in not being allowed to compete. Official’s decisions are final!
11. All track specific general safety rules or requirements will apply at all times to all participants (i.e. window nets, gloves, door plates, head and neck restraints, etc.) at that track.
12. RaceCeiver one way radios are REQUIRED at every sanctioned event. Failure to have a RaceCeiver (or equivalent one-way device) could result in disqualification. Malfunction of such device (i.e. dead battery, ear phone failure, etc.) will not constitute any penalty.
13. NO two-way radios, cell phones, smart watches, or other communication devices will be allowed. RaceCeiver is the ONLY communication device permitted. Drivers caught with any other communication device will be disqualified for that event (heat or feature). No lit signal devices allowed (light sticks, flashlights, cell phones, etc.)
14. No mirrors are allowed at any location on the car.
15. ALL weight/lead must be painted white and include the car number. Weight must be securely fastened to the car with a minimum two (2) ½” diameter bolts. No weight may be attached to the back bumper. Losing weight in any race (i.e. heat, b main, feature) will result in disqualification for that event. Page 1 of 11 Page 2 of 11
Technical Rules and Regulations:
It is the obligation of each participant to ensure their conduct and equipment are in compliance with all applicable rules and procedures, as they may be amended. Any amendment(s) will supersede any previous rules regarding that aspect of competition. An amendment is effective from the date it is added to the official rules regardless of when a competitor receives notice. Any new components (i.e. engine, suspension, body, frame, etc.) utilized in competition must be approved by GCRG officials before being allowed in competition. Failure to receive prior approval for any component may result in disqualification, loss of points and money, and a suspension or fine of the series choosing.
Engine Option Rule 1
1. Chevrolet Performance Part #88958602/19258602/88858602 (CT 350) commonly referred to as “602” engine and/or Chevrolet Performance Part #88958604/19318604 (CT400) commonly referred to as “604” engine.
2. Weights: a. CT 350 or “602” – 2,200 lbs. b. CT 400 or “604” – 2,300 lbs. c. 1 lb. per lap burn off during any race (Heat, B-Main, Feature, etc.) d. Cars MUST weigh required weight with NO BURNOFF for qualifying.
3. These engines are sealed at the intake manifold, cylinder head, front cover, and oil pan with Chevrolet Performance cap seals, which are installed at the Chevrolet Performance factory. Engines MUST be sealed in these six (6) locations with either Chevrolet Performance cap seals, or approved aftermarket seals.
4. The ONLY seals allowed for competition are: a. GM twist off bolts/engines will NOT be legal. b. Chevrolet Performance cap seals c. Crate USA Gen IV(Green) or Gen V(Black) cable seals, RUSH cable seals, IMCA cable seals allowed. d. NOTE: Crate USA Gen V (LIGHT BLUE) Seals are allowed. These seals will begin with number 406XXX. e. NO ACAS, NDRA, FASTRAK, Crate USA Gen I (Silver), Gen II (Blue) or Gen III (Yellow) will be allowed. f. To compete with ANY other seal/sealing system contact GCRG for approval.
5. Crate engines must not be altered, modified, or changed from factory specs, unless any such alteration, modification, or change is approved by GCRG. GCRG authorized rebuilders will be notified of any such alterations, modifications, or change. a. Approved changes/modifications for Chevrolet Performance 604 engines are noted as follows: i. Engine rings may be replaced with the Hastings Ring (Part #2M4626). ii. iii. Engine may run King (Part #MB5575I), Speed Pro (Part #139M) or Clevite “P” (Part #M5909P) Main Bearings. King (Part#CR8075I), Speed Pro (Part#8-7100CH), or Clevite “P” (Part #CB663P) Rod Bearings. No narrowed bearings. Timing cover may be replaced with Chevrolet Performance 602 Timing Cover (GM Part #12342089) and 602 Timing Tab (GM Part #12342011).
6. Any seals that have been removed or tampered with will make the engine illegal and not eligible for competition. The penalty for anyone tampering with seals, modifying any internal engine parts, or changing the parts from stock as delivered sealed from the factory will be subject to expulsion from racing in any GCRG sanctioned event for the remainder of the season and future seasons, as determined by officials.
7. No changes are allowed to the engine including the intake manifold, heads, valve covers, front cover, oil pan, harmonic balancer, or any other part(s) on or in the engine, unless noted otherwise or approved by GCRG officials. a. After much research, GCRG along with Chevrolet Performance officials determined that in some cases the original factory cylinder heads and valve springs do not meet the required correct install height. To correct this, shimming will be allowed to meet the correct install heights listed in the chart below. These updates are published in the Chevrolet Performance Technical/Specification Manual. Page 3 of 11 Page 4 of 11
Valve Spring Specifications -New (Unused) Description CT350 (602) CT400 (604) Valve Spring P/N 10212811 12551483 Diameter (A) 1.250” 1.32” Free Height (B) 2.021” 2.145” Installed Height (C) 1.70” 1.78” Lbs. @ installed height (+/- 4 lbs.) (D) 80 lbs. 101 lbs. Open Height (E) 1.270” 1.300” Open Pressure (+/- 8 lbs.) (F) 195 lbs. 260 lbs. Coil Bind (G) 1.20” 1.21” Wire Diameter .177” .178” CT 400 (604) Beehive Springs for Fastburn Heads Valvespring P/N 12625033 (Blue) Free Height 2.122” Installed Height 1.780” Lbs. @ installed height (+/- 4 lbs.) 98 +/- 4.5 lbs. Open Height 1.300” Open Pressure (+/- 8 lbs.) 267 +/- 13 lbs. Coil Bind 1.210” Wire Diameter Ovate [4.29 x 5.37] Retainer 19303149 (8 Pk) Mass 11.9 g Keeper 19302868 (16 Pk) Mass 3.9 g Spring Seat 19303150 (8 Pk) Valve Spring Service 12499224 (16 Pk)
8. No vacuum pumps. No evac systems of any type, including but not limited to the breather system style.
9. Engine’s Chevrolet Performance serial number, and when applicable, Crate USA build certification number, must be clearly visible to series technical inspectors.
10. Any new components, including engine components, suspension components, body designs, frame designs, and/or components of any type utilized in competition must be approved by GCRG before being introduced into competition.
Engine Option Rule 2
1-Block- 604 Gm Crate
2-Crankshaft – Stock GM 604 with stock GM 604 harmonic balancer
3-Rods – Stock GM 604 5.7
4- Piston- the following MAHL Part# only
930127811
930127815
930127820
920127830
5- Cam shaft -Max lift 505
6- Push Rods -Stock GM 604
7- Lifter - Stock style aftermarket replacement or stock Gm
8 -Oil pump Mellings part# M55HV or Gm Stock
Pickup tube Mellings part # 100SB
9 -Oil pan Champ Part # CP100LTRB or GM Stock
10- Cylinder Heads
-604 Gm unaltered aluminum cylinder head
-No Smaller than 58cc on the combustion chamber
-Valves- Stock GM or Stock Stainless Replacement. No Titanium
1.550” exhaust , 2.000” intake
-No Porting or Polishing
-Beehive Valve spring ok--- Not to exceed 100lbs of seat pressure
- Rocker Arms Gm Stock 1.5 only
- Must use stock gm Retainers and keepers
- Valve cover 604 GM stock
11- Intake
12- Timing Chain 604 Stock GM only. No Belt or gear driven
Engine Setback Rule:
Carburetor Rules:
1. One four (4) barrel carburetor only. Any manufacturer. Willy’s Equalizer Ok.
2. Must have conventional, “Holley” style boosters. No tunable boosters. No individual cylinder tuning.
3. Engine must be naturally aspirated.
4. CT 400 (604) Engines – may use one (1) carburetor spacer, one (1) inch, one-piece with .040 tolerance maximum) and two (2) standard paper gaskets (maximum 0.070 thick), one gasket between intake and spacer, and one gasket between spacer and carburetor.
5. CT 350 (602) Engines – may use one (1) carburetor spacer (two (2) inch, one-piece with .040 tolerance maximum) and two (2) standard paper gaskets (maximum 0.070 thick), one gasket between intake and spacer, and one gasket between spacer and carburetor.
6. Spacer MUST NOT extend into intake manifold at any point.
Distributor Rules:
1. Any standard distributor type electronic ignition allowed. MSD ok.
2. No magnetos and No crank triggers.
3. No electronic traction control devices allowed. Drivers finishing in the top 5 may protest another top 5 finishers box for $300. Series keeps $300 protest fee.
Starter Rule:
1. All cars must have a starter in working order. Water Pump Rules: 1. Cast or aluminum water pump permitted. 2. No electric water pumps. Page 5 of 11
Exhaust Rules:
1. Collector type headers required. Must have four (4) tube into one (1) collector. 2. Mufflers not required UNLESS track mandates them. If mandated, mufflers must have some type of internal noise dampening characteristics i.e. baffles, extruded holes, screen, chambered, etc. Mufflers must meet local speedway’s noise decibel requirements. 3. No tri-y headers or merged headers allowed. 4. No square tube headers.
Fuel, Fuel Cell, and Fuel Pump Rules:
1. An approved fuel cell, 32 gallon maximum, must be securely mounted in the trunk area of the car, inside a .20 gauge metal box supported by a minimum of 2” x 1/8” steel straps. Fuel Cell must have roll over check valve in fuel cell vent.
2. Fuel cell must be completely visible from rear of car.
3. Gasoline, Racing Gas, or E-85 fuel allowed. No methanol or alcohol. None of the following chemicals are allowed in any fuel used for competition: No nitrous oxide, propylene oxide, nitroethane, MTBE, hydrazine, or ethylhexanol. a. Gasoline or Race Gas – specific gravity NOT to exceed .744 at 60 degrees. Any gasoline or race gas with a specific gravity of .745 or greater will be disqualified. Fuel is subject to testing on site, or fuel samples may be taken and sent to an independent lab for testing. b. E-85 – specific gravity not to exceed .7855 at 60 degrees. Any E-85 with a specific gravity of .7856 or greater will be disqualified. Fuel is subject to testing on site, or fuel samples may be taken and sent to an independent lab for testing. c. It is the competitor’s responsibility to know what is being put into their fuel cell.
4. Drivers finishing in the top 5 may protest the fuel of car or cars finishing ahead of them. Protest fee is $150. Driver filing protest must have money with them and notify track or series official within 5 minutes of the checkered flag in that event. Fuel sample(s) will be taken and sent to an independent lab chosen by the series for testing. All official’s decisions and lab results are final and official.
5. Mechanical fuel pump only. Cam driven or belt driven.
6. No electric fuel pumps.
Body Rules:
1. See 2026 Body Diagram/Specifications for further body specifications.
2. Plastic body panels will be allowed, but must meet Body Specifications/Measurements.
3. No raised or gurney lips of any type allowed on body.
4. Doors and quarters must be flat or may have an outward roll. No doors or body panels allowed to be rolled inward.
5. Maximum distance between the bottom of the doors (measured at the back of the door) is 90” wide.
6. No tunneling of any type allowed underneath body, along frame, or around fuel cell area. 7. Stone shield for remote oil filter or transmission is allowed. 24” x 24” maximum, located near rear engine plate.
8. Stone shield along right side frame rail must remain behind right front assembly and may only be 36” maximum total from farthest point to farthest point.
9. Spoilers a. 8” maximum spoiler. Must be made of solid material such as Lexan, sheet aluminum, or material of equal strength. b. Spoiler and spoiler supports should be made of equal material and size on all areas. c. No open spoiler supports. d. Spoiler height, width, and angle must always be the same for the entire area of the spoiler. No varying spoiler heights or spoiler angles.
10. Roof supports or “C” pillars on both sides must be made of equal material. Page 6 of 11 11. Window openings are allowed but must be the same size opening on left and right side. If clear Lexan is used, it must be used on both sides. BOTH sides have be either open or both sides must be closed.
12. Left rear wheel opening between the quarter panel and the door must be a minimum of twenty-eight inches (28”) with a maximum of thirty-three inches (33”).
13. Right rear wheel opening between the quarter pane and the door must be a minimum of twenty-nine inches (29”) with a maximum of thirty-two inches (32”), and a maximum of nine inches (9”) from the top of the quarter panel to the wheel opening above the hub.
14. Curved or arced roof supports allowed. 3” maximum arc allowed at widest point. Will be checked with straight edge extended from roof edge to door edge.
15. Cars may NOT run topless. Topless races will not count for points, unless approved in advance, in which drivers will be given notice. These exceptions will be a rare occasion, or long-standing event, and not acceptable on a regular basis.
16. No mirrors at any location on the car.
17. No Radios, or any type of two-way communication. Raceiver one-way communication is the ONLY communication device. Please see Safety Rules for more info.
Frame Rules:
1. All frames must be of steel construction.
2. Square or rectangular frame must have a minimum of 2” x 2” material, .083 wall thickness.
3. Round frame tubing must have a minimum of 1 3/4" outside diameter, .083 wall thickness. Suspension Rules: 1. Standard Late Model suspension only. No spring loaded or shock type 4 bar rods. Only standard solid 4 bar rods. 2. Standards Late Model suspension equals one (1) shock per wheel, except on left rear. Left rear is allowed two (2) shocks: one in front of rear end and one behind. Shocks must be mounted vertical to axle tube, not horizontal. 3. No torsion bar on front or rear suspension. Sway bar ok.
4. Standard one-piece bird cages. No split bird cages.
5. Chassis brackets must be fixed. No movement.
6. Rear Travel Limiter (Droop Rule) a. A vertical travel limiting chain must be installed on the left rear of the car from the left rear axle housing to the frame. The travel limiting chain must attach to a bearing type mount or a clamp mounted bracket with the chain mounted to the top (12 o’clock) of the left rear axle tube, between the birdcage and the edge of the left rear bell of the axle housing, and to the left rear frame directly above the chain mount on the rear axle. Travel limiting chains must be installed so that when taunted they are as close to vertical as possible. One (1) compliance device may be used. The compliance device must not be more than one inch (1″) thick (without a load applied) and remain completely open and visible. Compliance devices can pg. 11 be rubber or any like material but must not be installed in any type of canister. Springs, spring-loaded, and/or pneumatic devices will not be permitted. No tapered, beveled, or roller skate type of compliance rubber will be permitted. Compliance devices must be solid material, same diameter top to bottom, not hollowed or drilled to soften the material. b. The travel limiting chain including the compliance rubber must be installed so that when the car is jacked up from the rear the chain assembly is tight (no slack). The travel limiting chain is subject to inspection at any time during the event at the discretion of the officials. Cars will be jacked up on the under-slung frame rail one inch (1”) in front of the rear axle tube, between the center of the rear axle and the panhard bar mount. The left rear under slung rail must be located between the left rear birdcage and the edge of the left rear axle housing bell. Cars will be jacked up until a forty-thousandths of an inch (.040”) shim will slide between the left rear tire and the ground. Once the car is jacked up as described a vertical measurement will be taken from the ground to the top trailing edge of the rear deck bar, six inches (6”) inboard of the left rear quarter panel outer edge. The measurement must not exceed fifty-one inches (51”). c. All droop limiter assemblies must support the unsprung mass of the rear-end. The stretched value of the droop limiter assembly may be no more than three-quarters of an inch (3/4”) at 1,200 lbs. The procedure: preload 100 lbs. zero (0) distance, pull to a value of 1,200 lbs.
Shock Rule:
1. Shocks at any position on the car, including lift bar and torque arm shocks, must be constructed of magnetic steel or aluminum.
2. Shocks of the “thru-rod” style are NOT permitted. Page 7 of 11
3. Remote reservoirs are permitted.
4. Each shock may have a maximum of three (3) external adjustment mechanisms. External reservoir may only have one (1) external adjustment. Adjuster mechanisms may not be hidden by the rod end. All adjusters must be located on the shock body, on the shock rod, or on the remote reservoir. Cockpit adjustable shocks NOT permitted.
5. No electronic adjustment whether hard wired or wireless. Remote nitrogen gas cannister will be permitted. The remote adjuster may contain compression adjustment.
6. Shock/Damper devices that are or can be referred to or defined as an “inerter” or referred to or defined as a “j-damper” are not permitted anywhere on the car.
7. All official’s decisions are final. Rules can and may be adjusted in order to maintain fairness. New or updated devices or suspension parts should be approved before use in competition. Wheelbase Rule: 1. 103” minimum wheelbase.
Roll Cage Rules:
1. All cars must have a suitable and deemed safe steel roll cage protecting the driver’s compartment, including headrest.
2. Side roll bars are mandatory and must extend into the door panels. A minimum of three (3) bars must be on the left side.
3. Each bar must be at least 1 1/2" in diameter, with a minimum material thickness of .083”.
4. Roll cages must be welded to frame.
Transmission Rules:
1. Must have at least one forward and one reverse gear in working order.
2. No straight drives or in and out boxes.
3. Drive shafts must be painted white for safety.
4. Carbon fiber drive shafts are legal.
5. Ball spline transmissions strongly recommended to run carbon fiber drive shaft only for safety.
Brake Rules:
1. Steel brake rotors only.
2. No carbon fiber, titanium, or other exotic material brake systems allowed.
Wheel Rules:
1. Any brand or type of wheel allowed.
2. Must be mounted with lug nuts.
3. No knock-off or center-lock wheels.
4. 14” maximum wheel width.
5. Wheel covers must be securely fastened. Recommend that wheel covers have a minimum of 5 mounting points. Wheel covers having only 3 attachment points must be bolted on at all 3 points using a minimum 1/4” or 5/16” magnetic steel hex head bolt and fastening (nut assembly) system. Cars that lose a wheel cover may be subject to disqualification.
Tire Rules:
1. Hoosier Racing Tire D-21 or a America Racer 48
a. D-21 must punch 46 or harder when checked cold. Series’ durometer is official durometer, and all official’s decisions are final. b. Any tire that fails to punch properly will result in disqualification of driver for remainder of the event. Any tire in question may be confiscated. c. Grooving and siping allowed. No needling. No drilling. Official’s discretion will be used, and all official’s decisions are final.
2. Hoosier Racing Tire D-55 or a American Racer 56
a. must punch 60 or harder when checked cold. Series’ durometer is official durometer, and all official’s decisions are final. b. Any tire that fails to punch properly will result in disqualification of driver for remainder of the event. Any tire in question may be confiscated. c. Grooving and siping allowed. No needling allowed. No drilling.
3. Grinding/Buffing of tire is permitted. No visual cuts should be present on tires. Use of carbide/nail style discs is prohibited.
4. All tire sidewall markings (i.e. compound, date code, shoulder plate, , etc.) must be visible and not removed or covered. Page 8 of 11
5. Tires must remain in factory manufactured condition. Any alterations from factory manufactured tire is prohibited. ALL decisions are FINAL. Series may or may not use laboratory testing to test for any alteration of tires, and tires must meet the factory supplied benchmark. If the inspected tire does not comply with this benchmark, the competitor will be disqualified. Series may use any means necessary to determine if tire(s) meet Hoosier and American Racer supplied benchmark, and that decision is the sole discretion of the series. All decisions are final.
6. Warning: GCRG American Racer tire and Hoosier Racing Tire strictly forbids any chemical alteration of the tire carcass and/or tread compound, such as but not limited to tire soaking or use of tread “softener”. American Racer Tire and Hoosier Racing Tire also forbid the physical defacement (altering, removal, or covering) of tire sidewall markings in any manner. Failure to comply with this warning could result in premature or catastrophic tire failure and may result in serious injury or death.
7. Drivers finishing in the top 5 may protest the tire of car or cars finishing ahead of them. Protest fee is $150. Driver filing protest must have money with them and notify track or series official within ten (10) minutes of the checkered flag in that event. Tire samples will be taken and sent to an independent lab chosen by the series for testing. All official’s decisions and lab results are final and official.
8. Penalties for illegal tires: a. First Offense - $500 fine and lose 100 championship points b. Second Offense - $1,000 fine and 1 race suspension from any GCRG sanctioned event and lose 200 championship points c. Third Offense - $2,000 fine and 3 race suspension from any GCRG sanctioned event and lose ALL championship points d. Failure to allow any tire(s) to be confiscated will result in an additional $500 per tire fine added to any other fines and penalties. All decisions are final.
Weigh-In Rules:
1. Series officials reserve the right to weigh any car at any time during any event.
2. The track scales or series scales used on site will be the official scales used to determine legality of weight.
3. Heat race and B-Main/Consolation race winners, transfer cars, and any cars instructed to do so, must proceed directly to the scales to be weighed immediately after the completion of the event. Do not go to your pit area before crossing the scales, as this will result in a disqualification.
4. The top 5 finishers in the feature event will be required to proceed directly to the scales at the completion of the main event.
5. A car failing to make weight on the first attempt will be allowed to be backed off the scales and rolled back on for a re weigh. This will be allowed ONE time and under the supervision/direction of Crate Racin’ USA officials.
6. Any car weighing light after qualifying or heat race, that car will be penalized to the rear of the next scheduled preliminary event.
7. Any car weighing light after the Main/Feature event will be penalized to the last finishing position.
Event Fines, Penalties, and Suspensions:
1. Pre-Race Technical Violation(s): Any technical violation(s) discovered during pre-race technical inspection, the driver will be notified of violation(s), and car must be fully in compliance before allowed to compete.
2. Legality of Part(s): Any question concerning legality of part(s) by GCRG or track technical inspector, the part(s) in question will be confiscated and sent to Chevrolet Performance or GCRG for further inspection. The finish for this race will be held until legality of part is determined. Points, monies, and finish will be adjusted in the event of a disqualification. Any parts deemed illegal will be confiscated. Failure to allow confiscation of any part will be penalized the same as an inside the sealing system engine infraction and penalized accordingly (see Engine Option #1 Penalty #1).
3. By entering and/or competing in any GCRG sanctioned event, drivers, car owners, and team members waive any right to file an appeal. All official’s decisions are final.
4. All decisions of series officials and/or the promoter regarding the application or interpretation of the rules, and the scoring of finishing positions shall be non-litigable. All participants agree that they will not initiate any legal action against GCRG, the promoter, or officials to challenge any decision, to seek monetary damages, to seek injunctive relief, or to seek any kind of legal remedy. Any such legal action pursued by a participant which violates this provision, the participant (driver) and/or owner expressly agrees to reimburse GCRG for all its attorney fees and costs in defending against such legal action.
5. By signing the annual membership/registration agreement, participants agree that they will comply with the written rules and procedures of GCRG. If the participant breaches this membership/registration agreement, he or she will be liable for actual and liquidated damages sustained by GCRG. Page 9 of 11
Code of Conduct and Conduct Penalties:
1. Drivers, car owners, and teams are to always conduct themselves in and orderly and professional manner while competing at any GCRG sanctioned event. Series director will judge incidents of conduct accordingly and use the following criteria to assess any penalties upon a driver, car owner, or race team as necessary.
2. Driver will be notified of penalties that have been levied by the series director. All series director’s decisions are final.
3. Series director may choose to levy monetary fines, suspension from sanctioned events, and deduct points as deemed necessary by the rules infraction or actions taken by a driver at any time. Series and tracks reserve the right to enforce or levy fines, points penalties, require changes, or suspension from competition for any actions deemed detrimental to the sport, series, or track. This includes, but is not limited to, social media posts, and/or derogatory or distasteful statements/slogans/photos/graphics on cars or any other driver related material visible to the public (i.e. helmets or driver’s suits, trailer or transporter, etc.).
4. Series will adhere to, and uphold any suspension levied on a driver by a specific track. If a driver has been suspended or barred from entering the property, that will be upheld by the series. Series and sanctioned event do not overrule a track’s decision to refuse entry to any driver, car owner, or crew member.
5. NOTE: These rules are not intended to eliminate competition or accidental contact. However, they are intended and may be used to penalize deliberate contact and/or over-driving or deemed deliberate acts of aggression towards other drivers.
6. No driver will be allowed to compete/participate while under the influence of any alcoholic beverage or illegal/controlled substances. If a driver is found to be participating in such a manner, that driver will be immediately suspended and removed from competing.
7. Any competitor that verbally abuses a series or track official by using profane and/or disrespectful language is subject to a fine of $100 for the first offense. A $300 fine, one-race suspension, and loss of points for the second offense. After a second offense, driver is subject to 30-day or longer suspension and loss of points as determined by officials.
8. Any physical confrontation, either on the track or in the pit area, will result in the aggressor(s) being suspended for one race, loss of points, and $300 fine for the first offense. A second offense will result in the driver being suspended for the remainder of the seasons, and a $500 fine.
9. Any driver who enters another driver’s pit area, or approaches another driver’s car on the speedway, will be deemed the aggressor. Away from either driver’s pit area, both drivers will be considered aggressors. Drivers should be aware that they are responsible for any member of their race team, and the above penalties will apply to the driver concerned even if the driver is not directly involved.
10. In the event of a felony conviction of a driver, team member, or team sponsor, disciplinary action could be a minimum of a 365-day ban from the series beginning with the date of the conviction or the date of the completion of any incarceration to said conviction, whichever date shall last occur.
11. Disciplinary action may also include, but is not limited to, the right of the series organizers and officials to suspend either temporarily, or permanently, any driver, team member or sponsor, whose actions, in the sole opinion and discretion of the series organizers and officials, may have resulted in, or may result in harm or detriment to GCRG
12. Any incidents occurring during the last five events of the season, may result in penalties being applied to the beginning of the following season.
13. Any incident(s) that are judged to be deliberate acts of aggression, whether on or off the track, under green or caution, will result in disqualification and a monetary fine to be determined by series’ officials.
14. Series officials reserve the right to increase the above penalties, by either adding additional money, suspension time, or points loss, depending on the severity of the incident. 15. Series officials reserve the right to revoke a competitor’s membership at any time. All official’s decisions are final.
16. Any threat of, or legal action taken or levied against the series by a driver/race team, will immediately result in that driver’s indefinite suspension from competition in any/all GCRG sanctioned divisions and events.
17. Any disqualification, other than a weight violation, will result in no points and no money for the event. Weight violation will move the driver to the end of the finish order.
18. The decisions made and disciplinary actions taken by the series and officials hereunder shall not be appealed by the driver, team member, or team sponsor affected thereby.
19. ALL OFFICIAL’S DECISIONS ARE FINAL. ATTENTION CAR OWNERS AND DRIVERS: Please remember that we are here and can race because of the fans, promoters, and sponsors. If they don’t benefit, we won’t benefit. While we understand that this competition involves substantial financial stakes, there is no excuse for bad or unruly behavior which would tend to bring the series, tracks, or sponsors into disrepute. Page 10 of 11 PLEASE NOTE: By entering, qualifying, and/or competing in a GCRG event, you are accepting these rules and regulations as being those under which you are prepared to race. Any driver entering and competing in a GCRG event acknowledges and accepts the following: GCRG and its assigns may use the drivers names, pictures, likeness, and performance in any way, medium, or material, including without limitation by and through, television, radio, air wave: cable and satellite broadcasts, film productions, videotape reproductions, audiotape reproductions, transmissions over the internet, and public and private on-line services authorized by the GCRG and the like, before, during, and after the event, for promoting, advertising, recording or reporting in the event or any other GCRG sanctioned event, and do hereby relinquish all rights there to for these purposes, provided however, that the car owner and driver shall retain the exclusive use of its or his/her name, picture and likeness in connection with product endorsements and the sale of products, services, concessions, and merchandise.
Gulf Coast Racing Group
BODY
1.1 Plastic and/or composite body panels are not allowed with the exception of the rear quarter panels and doors. Rear quarter panels and doors be constructed from a fire-retardant plastic or composite material.
1.2 Stock appearing front window support units must be used (painted roll bars are not acceptable substitutes). Front window may have a support of no more than twenty (20) inches at bottom, going straight up to top.
1.3 A minimum window opening of twelve (12) inches must be maintained on all four (front, back, left and right) window openings. An aluminum half-windshield may be used on driver’s side of the front window opening only, but may not extend more than six (6) inches past the steering wheel.
1.4 Streamlining at top of windshield is not allowed. Bodies must have standard appearing windshield opening and corner post must follow standard configuration.
1.5 Original roof line of vehicle (parallel to deck, front to back and side to side) must be maintained with a maximum of five (5) inches of slope from rear to front. Two (2) inch maximum roll, turned downward, is permitted along the front edge of the roof. No more than one (1) inch stiffener allowed at the rear of the roof and must turn down perpendicular to the ground. A one (1) inch roof lip is permitted on the left and right edges of the roof. A maximum of four (4) inch vertical sides on roof are permitted. Aluminum roofs are permitted but must remain flat and not concaved. The total height of the race car may not exceed fifty-six (56) inches, measured from the highest point on the car to the ground.
1.6 Sail panels may be solid or open and match design with matching styles on both sides of racecar. Open sail panels must have a minimum 2 inch wide border. Sail panels must extend from back of driver’s seat to a minimum length of at least three (3) inches from the spoiler support. Open sail panels may be no farther back than the front edge of the spoiler support. Solid sail panels may extend to the rear edge of the deck. Maximum radius of the front edge of the sail panel is three (3) inches. Sail panels may have a maximum outward consistent bow of four (4) inches from top to bottom, consistent arc of three (3) inches on top of sail panel front to back and may be no more than eight (8) inches above the back edge of deck and must not pass the rear edge of the deck, Sail panel must be mounted within one inch of the outer edge of the deck and flush with top of deck and outer edge of roof. Sail Panels, measured from side to side, must have matching top to bottom bow otherwise may not have more than five (5) inches of variance in material length when measured from roof line to deck.
1.7 Reverse hood rake is not allowed. Hood must be level or slope forward toward nose of racecar. Back of hood may be no more than two (2) inches above decking and sealed off completely. Lips on the sides of hood are not allowed. Hood must be flat from side to side (bowed or concave designs are not allowed).
1.8 Belly pans are not allowed. A belly pan will be defined as any object or material that alters the airflow under the racecar. A rock shield may be installed to protect the oil pan and the bottom of the motor, from the front cross member no further back than the rear engine mount (mid-plate/mid-mount) no wider than the radiator front to back.
1.9 Engine covers/panels in front of the door next to the engine compartment are permitted but must maintain a left-to-right gap of six (6) inches from the door. One side must remain open for inspection of engine on the scales.
1.10 Bodies with excessive damage (as determined by an official) will not be allowed to compete.
1.11 Overall width of the racecar may not exceed eighty (80) inches—NO TOLERANCE. Width shall be measured from the widest points on each side of the racecar. Exception is in front of left rear tire for tire clearance.
Deck & Trunk Area:
1.12.1 Rear deck lid and/or trunk area must be covered.
1.12.2 Deck length may be a maximum one hundred twenty (120) inches from rear of engine. 1.12.3 Droop rule 51 inches
1.12.4 Deck must remain parallel to the frame and chassis and the same width from front to back and front of deck must be level to the ground from side to side. Deck may be skewed to the right within four inches of parallel to motor measured at rear of deck. (see measurement “W” in body diagram).
1.12.5 Overall slope of deck may be a maximum eight (8) inches with a maximum four (4) inches slope from driver’s seat to rear of deck as measured from the ground.
1.12.6 Deck must remain flat side to side and front to rear, not concaved.
1.13 Door and quarter panel height may be a maximum thirty-seven (37) inches of total material. Doors and quarter panels may be mounted a maximum of one (1) inch above the deck and must match side to side—NO TOLERANCE. A maximum of five (5) inch plastic skirt on bottom of doors and quarter panels and nose piece is permitted. All body panels must remain outside of outer frame rails. Rear quarters must maintain standard size wheel opening. Rear edge of rear quarter panels must be square to top edge of quarter panel and may not extend past the rear of the decking or placed under the decking.
1.14 Excluding hood and nosepiece, the top of the body should extend no further forward than the back of the engine block. The bottom of the body may extend up to eight (8) inches forward of the back of the engine block.
Nose:
1.15.1 Maximum overall nose width is forty-two (42) inches. Nose must remain flat, parallel to the deck and may not be concaved.
1.15.2 Two (2) inch nose fins are permitted along both sides of the nose.
1.15.3 Nose fins may not pass the leading edge of radiator or continue past leading edge of hood.
1.15.4 All aluminum of the nose (including the fins) must be completely inside the outer edges of the bumper.
1.15.5 Nose fins must match side to side. If it is between nose fins, it is the nose; if it separates from the hood, it is the nose.
1.15.6 Plastic valances and/or nose pieces are permitted (P.N. MD3M21100). When using a plastic nose, the upper nose filler must have a horizontal brace every twelve (12) inches to prevent the panel from becoming concaved. Concaved noses are not allowed with any material used.
1.15.7 Aluminum or steel is not allowed outside the bumper. Plastic is allowed to extend outside of the bumper but must remain within the nose measurements.
1.15.8 All nose piece components must be a minimum of five (5) inches above the ground.
1.15.9 Maximum nose length (including plastic valance) is forty-two (42) inches as measured from the center of the lower ball joint—NO TOLERANCE.
Spoilers:
1.16.1 All spoilers shall be measured as complete material height including hinge and all hardware associated with connecting the spoiler to the decking.
Five (5) Inch Spoiler
1.16.2 Rear spoiler may not exceed the width of the rear deck lid, must be flush to the deck and must extend from right edge of deck to left edge of deck. Spoiler material must remain flat. A maximum single one (1) inch spoiler stiffener is permitted on the back side of the rear spoiler.
1.16.3 Rear spoiler must remain separate from sail panels.
1.16.4 A maximum of two (2) center supports and a maximum of two (2) side supports may be attached to the front of the rear spoiler (see body diagram for dimensions).
1.16.5 Fins, wings, lips, deflectors or other air spoilers (except as noted above) are not allowed. A maximum one-half (0.5) inch break for rigidity on body panels is permitted.
1.16.6 Any fins, wings, lips, deflectors or other permitted air spoilers must match corresponding part on opposite side of racecar.
Bumpers:
1.17.1 Center of bumpers (front and rear) must be a minimum sixteen (16) inches and a maximum twenty (20) inches from ground.
1.17.2 Both front and rear bumpers must be used and may not have any sharp edges (rounded corners only). Any inappropriate bumper may be disallowed at the discretion of an official. Front bumper should be mounted from frame-end to frame-end with the bottom loop parallel to ground. Bumpers must be made of a minimum of one and one-quarter (1.25) inch diameter tubing with a minimum wall thickness of sixty five one-thousandths (0.065) inch and must be able to support the racecar if lifted by a tow vehicle. Top bar must be directly above bottom bar.
1.17.3 Rear bumpers may be constructed of round tubing and must protect the fuel cell.
1.17.4 Any aluminum of the nose may not extend outside of front bumper.
1.17.5 Front bumper may be a maximum width of forty-six (46) inches from outside to outside.
1.17.6 Bumper may be no farther forward than forty-two (42) inches as measured from the center of the lower ball joints.
Appearance:
1.18.1 All racecars must be numbered with large legible numbers on both sides, on top and on the nose and real panels. Numbers on the sides of the racecar should be in contrasting color from the body and be at least four (4) inches thick and at least eighteen (18) inches high. Top numbers should be at least four (4) inches thick and twenty-four (24) inches high.
ROLL CAGE
2.1 The main roll cage must consist of continuous hoops of round steel tubing and must be acceptable to officials. Acceptable tubing is as follows: minimum one and one-half (1.5) inches diameter by ninety-five one-thousandths (0.095) inch wall thickness for main four-point roll cage. Any tubing measuring one and three-quarter (1.75) inches diameter must have a minimum wall thickness of eighty-three one thousandths (0.083) inch. Any tubing under one and three-quarter (1.75) inches diameter must be a minimum ninety-five one-thousandths (0.095) inch wall thickness tubing. Sliding or slip joint roll bar unions associated to the main roll cage are not allowed. A minimum of three (3) driver’s side door bars must be parallel to ground and located perpendicular to the driver to provide maximum protection for the driver, but without causing undue difficulty in getting in or out of the racecar. Side bars must be welded to the front and the rear of the roll cage members. Driver side door bars and uprights must be at least one and one-half (1.5) inches in diameter at a minimum of eighty-three one- thousandths (0.083) inch wall thickness. Steel door plate, 18 gauge or forty-nine one-thousandths (0.049) inch minimum thickness must be securely welded to outside of driver side door bars and cover area from top door bar to bottom door bar and from rear hoop down-post to five inches in front of seat. Passenger side must have at least one cross door bar, horizontal or angled, minimum one and one-quarter (1.25) inch O.D. with eighty three one thousandths (0.083) inch wall thickness, and one top horizontal door bar, minimum one and one-half (1.5) inch O.D. with eighty-three one thousandths (0.083) inch wall thickness. Roll bars within the driver’s reach must be padded with an accepted material as determined by an official. Fire retardant material is highly recommended. Installation and workmanship must be acceptable to officials. Must be frame-mounted in at least six (6) places. Must consist of a configuration of front and rear hoops connected by tubing on the sides or side hoops which meet the minimum tubing requirements in Rule 2.1. With helmet on and driver securely strapped into the racing seat, top of driver’s head must not protrude above the roll cage. Must have a cross bar in halo. Must have a protective screen or bars in front window opening in front of driver’s face. Protection of driver’s feet utilizing a bar across the back of the engine with vertical bars and rub rails or similar protection is mandatory. Brace bars forward of roll cage may not be higher than the stock hood height. Adjustable bars on the frame and/or roll cage are not allowed, Removable bars are permitted. Roll cages that fail to meet these regulations will be subject to monetary fines and associated penalties.
FRAME
Factory production complete full-perimeter 1960 or newer parallel American passenger car frames only. Frames may be cut in rear only at a point equal to or behind rear of engine. May only be altered for the installation of springs and shocks. All components must be made of steel and be properly welded. Must be full and complete on both sides, may not be widened or narrowed and must be able to support roll cage on both sides. All factory holes must be present for inspection. All measurements must meet the frame diagram tolerances listed or be within one half (0.5) inch (either way) of OEM measurements on any measurement not listed on frame diagram—NO TOLERANCE.
3.5 Right outer front frame rail must be at factory height and may not be raised (see measurement “L” in Frame Diagram). Minimum height from ground is four (4) inches. Maximum height from ground is seven and one-half (7.5) inches (Exception: front cross member)—NO TOLERANCE.
3.6 Rear of frame may be altered to accept leaf or coil springs.
3.7 Hydraulic, ratchet or electric weight jacks are not allowed anywhere on the racecar. Aluminum jack bolts are not allowed.
3.8 Wheelbase must be a minimum of one-hundred eight (108) inches on both sides (no tolerance).
3.9 Tubular front clips are not allowed.
3.10 Maximum overall width of car (at front or rear) shall not exceed eighty (80) inches—NO TOLERANCE (Exception: door in front of left rear tire for tire clearance).
3.11 Rear of engine (bell housing flange) must be mounted at least seventy-two (72) inches forward from the center line of the rear axle—NO TOLERANCE.
COCKPIT, STEERING & SEAT
4.1 Loose objects and/or weights are not allowed.
4.2 Air bags are not allowed. Rear view mirrors are not allowed.
4.3 Other than the gas pedal, brake pedal and front-to-rear brake bias, any knobs, handles or levers used for adjustment of anything like carburetor, ignition timing and/or suspension is not allowed.
4.4 Floor and firewall must be complete in the driver’s compartment. Minimum one eighth (0.125) inch aluminum, or six one hundredth (0.06) inch steel, complete floor pan required. No interior sheet metal can be higher than or enclose a standard window opening. Sheet metal in the driver’s compartment must be horizontal from the top of the driver shaft tunnel to the right side door bars or angle from the top of the drive shaft tunnel upwards to the top of the right side door bars. Driver must be able to exit the racecar from both sides.
4.5 Steering:
4.5.1 Must be OEM and remain within original bolt pattern for type of frame used. Center link must match frame. Inner and outer tie rod end and adjustment sleeve may be replaced with a heim end and steel tube.
4.5.2 Rack and pinion is not allowed.
4.5.3 The 600 Power Steering Gear Box is not allowed.
4.5.4 May be modified to suit driver but must remain on left side of cockpit (no center steering).
4.5.5 Quick-release metal coupling on steering wheel is mandatory. Plastic couplings are not allowed.
4.6 Seat:
4.6.1 Factory-manufactured racing seats are mandatory and must be acceptable to officials.
4.6.2 Homemade aluminum, plastic or fiberglass seats are not allowed.
4.6.3 Must be properly installed and seat back cannot be moved back further than the front edge of sail panel.
4.6.4 High-back aluminum seats only. Full containment racing seats are strongly recommended.
SUSPENSION
5.1 Packers, bumps stops, biscuits, chains or any other material meant to limit suspension travel is not allowed unless noted below (Exception: Bump stops and/or various rubber biscuits are permitted in conjunction with the pull bar, rear limiting chains, lift arm chain, right front shock or a single block from rear-end housing to underslung chassis). Air bumps, spring bumps and/or steel spacers or shims are not allowed.
5.2 Suspension and/or rear end parts must be made of steel. Aluminum and/or titanium components are strictly forbidden. Aluminum J-bar brackets (chassis and pinion), upper A-frame cross shafts and limiter chain brackets are allowed.
5.3 All chassis brackets and/or mounts must be welded or securely bolted to the chassis. Floating, pivoting and/or rotating mounts and/or brackets of any sort are strictly forbidden. Gun-drilled, tubular or hollow bolts or studs are not allowed anywhere on the racecar.
5.4 Suspension covers are not allowed. Tarps or covers are not allowed on racecar in the tech area.
5.5 Front Suspension:
5.5.1 Front suspension must remain stock type for the type of frame being used. Steel aftermarket parts may be used as stock components but must mount in the stock location and be the same size as the OEM parts. This includes lower tubular A-frames. If using lower tubular A-frames, they must match factory specs. All parts must meet OE specs and match side to side. GM 1978-1988 metric “G” body frames are permitted to use the Nova lower “A” frames. Bottom A-frames may not be altered, lightened or moved and must match side to side.
5.5.2 Steel tube-type upper A-frames are permitted and may be moved. Steel or aluminum cross shafts are permitted.
5.5.3 Only stock passenger car spindles are permitted and must match side to side with make and dimensions. Fabricated spindles and/or steering arms are not allowed.
5.5.4 Front sway bars may be utilized. Front sway bars must be made of steel and may be attached to the bottom A-frame using steel heim joints (must be solid, full-length OEM).
5.5.5 Coil-over springs are not allowed on the front.
5.5.6 Front chains on front end are permitted but must be mounted from lower A-frame to frame or cage and remain loose at ride height.
5.5.7 Maximum front frame height as measured from the ground is seven and one-half (7.5) inches.
5.6 Rear Suspension:
5.6.1 All rear suspension radius rods must be hollow tube, one (1) inch maximum O.D. of a fixed solid steel design.
5.6.2 Only two (2) radius rods per side are permitted. One additional rod per side is permitted for brake floater only.
5.6.3 Only one (1) single unit birdcage per side is permitted. Birdcage must spin freely forward and backward. Locked bird cages are not allowed. Car must return to a normal ride height when off throttle, under cautions and after a completed race. Radius rods must mount to birdcage or solid on rear end housing. If one radius rod is on a bird cage, then all rods must be on bird cages. One additional floated birdcage style bracket and radius rod is permitted per side to accommodate floated brake system only.
5.6.4 Springs and /or shocks may be mounted to birdcage or lower radius rod or solid on rear end housing. If mounted on housing, it may be no more than seven (7) inches from center of axle tube and mounted solid.
5.6.5 Only one (1) mechanical traction device is permitted. Only one (1) pull bar or one lift arm is permitted.
5.6.6 Pull bar is defined as a continuous assembly that is connected to the top of the rear end and extends forward to a solid mounting point located on the chassis. The mounting location at both the front and rear of the pull bar may be adjustable but must remain constant during competition (cannot be adjustable from the cockpit). A lift arm is defined as a solid steel triangulated bar that is connected at the top and bottom of the rear end housing and extends forward where it is connected to a shock or shock spring coil-over combination and a limiting chain (with or without a biscuit for cushion). One stabilizer bar is permitted.
5.6.7 Steel coil-over eliminators and/or steel-aluminum coil-over kits are permitted on the rear only.
5.6.8 Rear panhard bars are permitted but must be made of steel and may be attached by using a minimum three-quarter (0.75) inch i.d. steel heim joint.
5.6.9 Vertically mounted steel limiting chains (with or without rubber bump stops) may be utilized in the rear of the race car. Chain may be mounted to floating or bearing-type brackets on the rear end. A maximum of one (1) chain per wheel is permitted. Must remain loose at ride height.
Shocks
5.7.6 Inerter shocks, J-damper shocks, active mass damper shocks and/or through-rod-designed shocks are not allowed. Bump stops, spring rubbers or any other limiting devices are not allowed on any suspension component (Exception: Bump stops and/or various rubber biscuits are permitted in conjunction with the pull bar, rear limiting chains, lift arm chain or a single block from rear-end housing to chassis, and any size external bump stop on right front shock is permitted). Electronically-controlled and/or monitored shocks by any means or methods is strictly forbidden. Cockpit adjustable shocks are not allowed. Shock covers are permitted but may cover only front half of shock and must be mounted directly to shock. 5.7.10 Shocks shall be subject to claim, as outlined in Claim Procedures
Springs: One spring per wheel is permitted. One additional spring is permitted in the center of the car pertaining to the pull bar or lift arm. All coil springs must be at least four and one-half (4.5) inches outside diameter (except pull bar and lift arm). Springs must be made of steel. Torsion bars in the rear are not allowed. Stacked, tapered, preloaded and/or welded springs are not allowed. Progressive springs are not allowed (except on pull bar or lift arm). Spring wire diameter and coil spread must remain consistent from one end to the other. Only conventional spring mounting devices are permitted. Widgets, trick and/or spring-altering mounting devices are not allowed.
TIRES & WHEELS
Wheels: Must be fifteen (15) inches in diameter and eight (8) inches in width. Stickers are not required. Must be reinforced steel only. Added ballast to wheels is not allowed. Solid and/or non-spoked wheels are not allowed. A steel or aluminum bead lock may be used on the right front and right rear wheels only and may be mounted on the outside of the wheel so long as it does not add over three-quarters (0.75) of an inch to the overall width of the wheel. Homemade mud caps are not allowed. Wheel covers are permitted on right side wheels only (5 fastener type recommended). Inner mud plugs are permitted. All mud covers must display car number on at least one side. Wide five wheel adaptors are not allowed. Spacer between hub and wheel is permitted but must be made of aluminum only and overall width of racecar cannot exceed eighty (80) inches (see Rule 1.11). Aluminum or steel lug nuts are permitted.
Tires: American Racer G60-15 KK704 (Short, Tall or X-Tall) Hoosier G-60 . Tires should durometer 50 or harder after any race. Any tire not meeting this durometer reading is subject to having a tire sample sent in for chemical testing. Softening is not allowed. Solvents of any kind are not allowed. Altering tires with any components or chemicals which alter the manufacturer’s baseline-settings of the tire is not allowed. Grooving and/or siping is permitted. 8.2.4 All sidewall markings must remain visible always. Buffing or removing of the compound designations is not allowed. 8.2.5 Adding ballast to the inside of the tire is not allowed. 8.2.6 Plastic wrap on tires is permitted in your pit area but must be removed before leaving your pit stall. 8.3
Tire Testing Procedures:
8.3.1 Random GC (gas chromatography) scans may be performed to identify illegal substances. A GC scan should always be at a peak in 19-20 minutes. If there is no peak, the driver will be disqualified. Driver may protest the GC scan results and request a mass spec test at the cost to the driver (usually around $300). The mass spec test will reveal exactly what substance was used. The main peak of the tire should never be in half.
8.3.2 Traces of chemicals and/or excessive quantities of chemicals found to be outside the baseline on any test is automatic disqualification. First offense shall result in loss of all points accumulated for the season, forfeiture of all prize money earned for the event, up to a $5,000 fine and an indefinite suspension from USMTS-sanctioned events. Driver will not be permitted to compete in any future USMTS event until fine is paid in full.
8.3.3 It is strongly recommended that all drivers use only soap and water. Baking tires will not eliminate traces of illegal substances. The USMTS will aggressively test for illegal substances and will levy severe punishment for infractions.
DRIVE SHAFT
10.1 A loop is required and must be constructed of at least one-quarter (0.25) inch by two (2) inch solid steel. Loop must be mounted no more than six (6) inches from the front of the drive shaft tube. Alternatively, two (2) loops of one-quarter (0.25) inch by one (1) inch solid steel fastened to cross member are permitted.
10.2 Drive shafts must be painted white.
10.3 Aluminum drive shafts are not allowed. Steel or carbon fiber drive shafts only (carbon fiber may have aluminum yokes).
Weight – 2450lbs
14.5.2 Must be securely mounted, painted white and clearly marked with the car number.
14.5.3 Must be attached with at least two (2) one-half (0.5) inch bolts per a maximum one hundred (100) pounds of ballast. Any ballast weighing twenty-five (25) pounds or less may be mounted with a single one-half (0.5) inch bolt.
14.5.4 Must be attached to the frame, roll cage or rear-end housing. May not be attached to rear bumper.
SAFETY
It is recommended that each racecar have built-in fire extinguishing equipment but cannot be of the dry powder type (must be Halon 1211 or equivalent). Drivers should have in their pit area as part of their equipment, always, a fully charged dry chemical, Halon (or its equivalent) fire extinguisher. Ten- or thirteen-pound fire extinguishers are recommended. Driver must wear required helmet, fire suit and five-point safety harness whenever the racecar is on the racetrack. This includes during track packing, warm ups, hot laps and races. Helmets are mandatory and must be certified SA2015 or SA2020. Helmet must accompany driver and racecar at time of inspection. Complete one- or two-piece fire suits of a flame-retardant nature are mandatory. Fire-resistant gloves and shoes are mandatory. Fire-resistant socks are recommended. The use of a five- six- or seven-point driver restraint system (safety belts, sub-belt and shoulder harness) is required. Factory-type shoulder belts or straps are not allowed. The use of a seven-point driver restraint system is recommended. Shoulder harness must be mounted to main cage and not the tail section of car. Metal to metal buckles are required on shoulder and seat belts.
15.10 Shoulder harness must be mounted securely to the roll cage.
15.11 Where the belt passes through the seat edges, a grommet must be installed, rolled and/or padded to prevent cutting of the belt.
15.12 Driver restraint system must be less than three (3) years of age past the date of manufacture. It is recommended that the driver restraint system be no more than two (2) years past the date of manufacture.
15.13 Full-size window net mounted in the left side driver’s window opening is required. Window net mounts must be welded or securely bolted to the roll cage. All bars around the driver must have approved roll bar padding. Approved racing arm restraints are recommended. Window net mounts are highly recommended to be securely welded or bolted to the inside of the main roll cage on top.
15.14 Fire-resistant safety neck collars are mandatory.
15.15 Absolutely no plastic except from edge of firewall to body skin and inner wheel tub to body skin.
Gulf Coast Racing Group
General Rules:
1. The Rules and/or Regulations set forth herein do not express or imply warranty of safety from publication of or compliance with Rules and/or Regulations. These rules are intended as a guideline for the conduct of Gulf Coast Racing Group Street Stock Division events, and are in no way a guarantee against injury or death to participants, spectators, or officials.
2. The Rules and/or Regulations will apply to all GCRG Street Stock Division sanctioned events. The Rules and/or Regulations will also apply to events sanctioned by the GCRG Street Stock Division.
3. GCRG officials shall have full authority over said sanctioned events, and in the event of any dispute, the head official’s decision will be final.
4. All competitors and cars are subject to inspection by GCRG Technical Inspectors or their representatives at any time during any event.
5. GCRG, and it’s officials and representatives reserve the right to confiscate any suspicious or deemed illegal parts or components.
6. GCRG reserves the right to alter or amend these Rules and/or Regulations in the interest of fair competition, efficient completion of an event, or for safety. All official’s decisions are final.
7. There is NO appeal process in the determination of or application of fines and/or penalties assessed by the series. All official’s decisions are final, and drivers will not be allowed to compete in any sanctioned events until all fines are paid, penalties assessed have been cleared, and/or suspensions have been served.
Safety Rules:
1. Safety is the primary responsibility of the RACER!!
2. SFI-Approved full fire suit (top and bottom) and shoes required. Racing gloves REQUIRED.
3. Snell rated SA2020 or SA2025 full-face helmet required.
4. Series recommends the use of a head and neck restraint system, but is not required. Full containment seats will be required.
5. All cars must have a fully charged 2 lb. fire extinguisher mounted within reach of the driver. Series recommends a 5 lb. halon system.
6. All cars must have a kill switch within easy reach of the driver, and clearly marked “Off” and “On”.
7. All cars must have a quality fuel cell with roll over valve (check valve) in fuel cell vent.
8. Minimum three (3) inch wide, or two (2) inch if using head and neck restraint, SFI-Approved five point safety belts, mounted securely to the roll cage. Belts cannot be used past their expiration date or two (2) years past their date of manufacture.
9. Any pre-race technical/safety inspection and car or equipment is deemed unsafe by officials will result in not being allowed to compete. Official’s decisions are final!
10. All track specific general safety rules or requirements will apply at all times to all participants (i.e. window nets, gloves, door plates, head and neck restraints, etc.) at that track.
11. RaceCeiver one way radios are REQUIRED at every sanctioned event. Failure to have a RaceCeiver(or equivalent one-way device) could result in disqualification. Malfunction of such device (i.e. dead battery, ear phone failure, etc.) will not constitute any penalty.
12. NO two-way radios, cell phones, smart watches, or other communication devices will be allowed. RaceCeiver is the ONLY communication device permitted. Drivers caught with any other communication device will be disqualified for that event (heat or feature). No lit signal devices allowed (light sticks, flashlights, cell phones, etc.)
13. No mirrors are allowed at any location on the car.
14. ALL weight/lead must be painted white and include the car number. Weight must be securely fastened to the car with a minimum two (2) ½” diameter bolts. No weight may be attached to the back bumper. Losing weight in any race (i.e. heat, b main, feature) will result in disqualification for that event.
Technical Rules and Regulations:
It is the obligation of each participant to ensure their conduct and equipment are in compliance with all applicable rules and procedures, as they may be amended. Any amendment(s) will supersede any previous rules regarding that aspect of competition. An amendment is effective from the date it is added to the official rules regardless of when a competitor receives notice. Any new components (i.e. engine, suspension, body, frame, etc.) utilized in competition must be approved by GCRG officials before being allowed in competition. Failure to receive prior approval for any component may result in disqualification, loss of points and money, and a suspension or fine of the series choosing.
Engine Rules:
Engine Option #1:
1. Weight = 2,800 lbs. 8” maximum spoiler and spoiler fins. No lead or weight allowed above decking.
2. Chevrolet Performance Part #88958602/19258602/88858602 (CT 350) Commonly referred to as “602” engine.
3. These engines are sealed at the intake manifold, cylinder head, front cover, and oil pan with Chevrolet Performance cap seals, which are installed at the Chevrolet Performance factory. Engines MUST be sealed in these six (6) locations with either Chevrolet Performance cap seals, or approved aftermarket seals.
4. The ONLY aftermarket seals allowed for competition are: a. GM twist off bolt engines will NOT be legal. b. Chevrolet Performance cap seals c. Crate USA Gen IV(Green) or Gen V(Black) cable seals, RUSH cable seals, IMCA cable seals allowed. d. NOTE: Crate USA Gen V (LIGHT BLUE) Seals are allowed. These seals will begin with number 406XXX. e. NO ACAS, NDRA, FASTRAK, Crate USA Gen I (Silver), Gen II (Blue) or Gen III (Yellow) will be allowed. f. To compete with ANY other seal/sealing system contact Crate Racin’ USA for approval.
5. Crate engines must not be altered, modified, or changed from factory specs, unless any such alteration, modification, or change is approved by GCRC. GCRG authorized rebuilders will be notified of any such alterations, modifications, or change. a. Approved changes/modifications for Chevrolet Performance 602 engines are noted as follows: i. Engine rings may be replaced with the Hastings Ring (Part #2M4860) ii. Engine may run King (Part #MB5575I), Speed Pro (Part #139M) or Clevite “P” (Part #M5909P) Main Bearings. King (Part#CR8075I), Speed Pro (Part#8-7100CH), or Clevite “P” (Part #CB663P) Rod Bearings. No narrowed bearings.
6. Any seals that have been removed or tampered with will make the engine illegal and not eligible for competition. The penalty for anyone tampering with seals, modifying any internal engine part s, or changing the parts from stock as delivered sealed from the factory will be subject to expulsion from racing in any GCRG sanctioned event for the remainder of the season and future seasons, as determined by officials.
7. No changes are allowed to the engine including the intake manifold, heads, valve covers, front cover, oil pan, harmonic balancer, or any other part(s) on or in the engine, unless noted otherwise or approved by GCRG officials.
8. No vacuum pumps. No evac systems of any type, including but not limited to the breather system style.
9. Engine’s Chevrolet Performance serial number, and when applicable, Crate USA build certification number, must be clearly visible to series technical inspectors.
Engine Claim Procedure: • Driver’s finishing in the top 5 may claim/purchase the engine of any car finishing ahead of them. Claim fee is $6,000 or current cost from Chevrolet Performance dealer, whichever is greater (Rogers Dabbs Performance Parts). Engine claimed will be just as it comes from Chevrolet Performance and WILL NOT include any accessories, carburetor, water or fuel pump, wires, distributor, etc. Refusal of claim will result in immediate disqualification and penalized the same as an engine that was found illegal inside the seal system (infraction penalty #1 below). • Competitor, either driver or car owner, finishing in the top five of the feature race, must hand a GCRG or track official $6,000 cash or current cost from dealer, whichever is greater, within ten (10) minutes after the checkered flag falls on the feature race. • Engine will be removed, confiscated, and inspected by GCRG officials at an agreed upon time and place upon being claimed. If legal, competitor claiming engine will receive the engine and will have to have engine re-sealed by a certified rebuilder of their choice. Series will provide seals for re-sealing. If engine is found to be illegal, driver being claimed will be penalized as outlined in infraction penalty #1 below and claiming driver will receive refund of their claim money.
Engine Protests:
1. Protest fee for a complete tear down on an engine that finishes the feature event is $1,500. Complete tear down is the only option available. The protest fee must be paid to the race director or technical director, in cash, within 10 minutes after the checkered flag has fallen on the feature. Must finish in the top 5 to be eligible to protest. $200 of protest fee will go to the track. $200 will go to the series. Remainder of the protest money ($1,100) will go to the winner of protest. Any part or parts found to be illegal will be confiscated.
2. Any time an engine is protested, and driver/car owner accepts the protest and agrees to tear down, the engine being protested, along with the carburetor, must be removed and impounded by racetrack immediately. Arrangements for GCRG Technical Director to inspect engine will be made, and parties involved will be made aware of time and location of inspection that is suitable to all. Any refusal for removal, impound, or inspection will result in disqualification.
3. There will be NO counter/reverse protesting or claims allowed (cannot protest car finishing behind you).
4. If an engine is torn down by series’ or track officials, and not protested by another driver, series will provide gasket set and Crate USA engine seals to the Certified Rebuilder of Tracks choice.
6. Only two (2) people from the car being protested, and the driver filing the protest will be allowed in the determined tech area during any tear down. Driver initiating the protest must be present, unless extreme circumstance and arrangement is made with officials. All official’s decisions are final.
6. Failure and/or refusal to tear down any engine or refusal to allow your car to be inspected by series officials at any time will result in a 365-day suspension and a fine in an amount to be determined by series officials. Engine Infraction Penalties: 1) Any violation of the engine rules and/or factory specs inside the sealing system of the engine will result in the driver and/or owner being disqualified from that event and suspended from series competition for 365 days and pay a $1,000 fine. After that period, the driver can only compete in series events with an engine equipped with original factory GM seal bolts, CP cap seals, or Crate USA seals from an authorized rebuilder approved and authorized by Crate Racin’ USA officials. Driver and/or owner will be notified in writing of series’ decision, via certified mail. All official’s decisions are final. 2) Any violation of the engine rules and/or factory specs outside the sealing system of the engine will result in the driver being disqualified from that event. Driver and/or owner may be suspended from series competition for up to but not more than 30 days and fined up to but not more than $500 at series’ officials’ discretion. Driver and/or owner will be notified in writing of series decision. All decisions are final.
Engine Option #2:
1. 362 cubic inch maximum, factory steel production blocks. May run factory replacement DART SHP block – part #31161111.
2. Weight = 3,000 lbs. Maximum 8” spoiler and spoiler fins. No lead or weight allowed above decking.
3. Any cast iron 23 degree steel heads. No porting or polishing of cylinder head. No aluminum heads.
4. Max valve size: 2.02” intake, and 1.6” exhaust.
5. Any intake manifolds. No porting or polishing.
6. Steel or cast cranks and rods. No exotic material cranks or rods (ex.: aluminum or titanium)
7. Flat top pistons only.
8. Any flat tappet camshaft only. No roller cams.
9. Timing chains only. No gear drives.
10. Stud mount rockers only. No stud girdles.
11. Stock diameter valve springs only. 1.260” maximum O.D. Beehive springs allowed, 1.320” maximum O.D., ANY manufacturer (Chevy, Ford, or Dodge). NO double valve springs.
12. Driver’s finishing in the top 5 may claim/purchase the engine of any car finishing ahead of them. Claim fee is $11,000. Engine claimed will be long block/engine only and WILL NOT include any accessories, carburetor, water or fuel pump, wires, distributor, etc. Refusal of claim will result in immediate disqualification and penalized the same as an engine that was found illegal inside the seal system (infraction penalty #1 below).
Engine Option #2 Claim Procedure:
• Competitor, either driver or car owner, finishing in the top five of the feature race, must hand a GCRG or track official $11,000 cash within ten (10) minutes after the checkered flag falls on the feature race. • Engine will be removed, confiscated, and inspected by GCRG officials at an agreed upon time and place upon being claimed. If legal, competitor claiming engine will receive the engine only, as is. If engine is found to be illegal, driver being claimed will be penalized as outlined in infraction penalty #1 below and claiming driver will receive refund of their claim money.
Engine Option #2 Infraction Penalties:
1) Any violation of the engine rules and specs internally or within the seal of the engine will result in the driver and/or owner being disqualified from that event and suspended from series competition for 365 days and pay a $1,000 fine. Driver and/or owner will be notified in writing of series decision. All decisions are final.
2) Any violation of the engine rules and/or factory specs outside the sealing system of the engine will result in the driver being disqualified from that event. Driver and/or owner may be suspended from series competition for up to but not more than 30 days and fined up to but not more than $500 at series’ officials’ discretion. Driver and/or owner will be notified in writing of series decision. All decisions are final.
Engine Protests:
8. Protest fee for a complete tear down on an engine that finishes the feature event is $1,200. Complete tear down is the only option available. The protest fee must be paid to the race director or technical director, in cash, within 10 minutes after the checkered flag has fallen on the feature. Must finish in the top 5 to be eligible to protest. $100 of protest fee will go to the track. $200 will go to the series. Remainder of the protest money ($900) will go to the winner of protest. Any part or parts found to be illegal will be confiscated.
9. Any time an engine is protested, and driver/car owner accepts the protest and agrees to tear down, the engine being protested, along with the carburetor, must be removed and impounded by racetrack immediately. Arrangements for GCRG Technical Director to inspect engine will be made, and parties involved will be made aware of time and location of inspection that is suitable to all. Any refusal for removal, impound, or inspection will result in disqualification.
10. There will be NO counter/reverse protesting or claims allowed (cannot protest car finishing behind you).
11. Any GCRG sanctioned track is authorized to call for or arrange an engine inspection by the Technical Director at any time. If this occurs, track will remove the engine and carburetor, and impound until arrangements can be made to inspection time suitable for all involved.
12. If an engine is torn down by series’ or track officials, and not protested by another driver, series will provide gasket set and Crate USA engine seals to the Certified Rebuilder of choice, of the driver being torn down.
13. Only two (2) people from the car being protested, and the driver filing the protest will be allowed in the determined tech area during any tear down. Driver initiating the protest must be present, unless extreme circumstance and arrangement is made with officials. All official’s decisions are final.
14. Failure and/or refusal to tear down any engine or refusal to allow your car to be inspected by series officials at any time will result in a 365-day suspension and a fine in an amount to be determined by series officials.
Engine Setback Rule:
1. Engine must be mounted in stock location, in center of chassis. #1 spark plug must be in front of or centerline of upper ball joint. 2. Weight penalty of 50 lb. per ½” will be added forward of water pump for improper setback.
Carburetor Rules:
1. Engine Option #2 – 500 CFM 2 barrel only.
2. 2 Barrel carburetor will be checked with go-no-go gauges top to bottom.
3. Either engine Option may run 1” maximum carburetor spacer, .040” tolerance. At no point may spacer extend into intake manifold area. Two (2) standard thickness carburetor gaskets, .070” maximum thickness allowed.
4. Engine Option #1 – may run one (1) four-barrel carburetor only. Chevrolet Performance 602 Circle Track Engines perform best with a quality 650 CFM carburetor.
5. All carburetors (for both engine options) must have conventional style floats along with needles and seats. NO individual cylinder tuning or equivalent allowed.
6. All carburetors (for both engine options) must have conventional “Holley-style” straight or down leg boosters. NO exceptions. NO super bowl type carburetors allowed. Willy’s Equalizer Carburetor OK.
Distributor Rules:
1. Any standard distributor type electronic ignition allowed. MSD ok – 6 AL or 6 ALN only.
2. No magnetos and No crank triggers.
3. No electronic traction control devices allowed. Drivers finishing in the top 5 may protest another top 5 finishers box for $300. Series keeps $300 protest fee. Gauges and Interior: 1. No GPS enabled data logger dash kits such as Motec, Mychron, FuelTech, AIM, Racepak, etc. May ONLY use standard, conventional style gauges and tachometer.
Starter Rule:
1. All cars must have a starter in working order. Starter must be mounted in stock location. NO reverse mount starters.
Water Pump Rules:
1. Stock type cast or aluminum water pump permitted.
2. No electric water pumps.
3. Manual fans only. No electric fans.
Exhaust Rules:
1. Collector type headers required. Must have four (4) tube into one (1) collector.
2. Mufflers not required UNLESS track mandates them. If mandated, mufflers must have some type of internal noise dampening characteristics i.e. baffles, extruded holes, screen, chambered, etc. Mufflers must meet local speedway’s noise decibel requirements.
3. No tri-y headers or merged headers allowed. 4. No square tube headers.
Fuel, Fuel Cell, and Fuel Pump Rules:
1. An approved fuel cell must be securely mounted in the trunk area of the car, inside a .20 gauge metal box supported by a minimum of 2” x 1/8” steel straps.
2. Gasoline, Racing Gas, or E-85 fuel allowed. No methanol or alcohol. None of the following chemicals are allowed in any fuel used for competition: No nitrous oxide, propylene oxide, nitroethane, MTBE, hydrazine, or ethylhexanol. a. Gasoline or Race Gas – specific gravity NOT to exceed .744 at 60 degrees. Any gasoline or race gas with a specific gravity of .745 or greater will be disqualified. Fuel is subject to testing on site, or fuel samples may be taken and sent to an independent lab for testing. b. E-85 – specific gravity not to exceed .7855 at 60 degrees. Any E-85 with a specific gravity of .7856 or greater will be disqualified. Fuel is subject to testing on site, or fuel samples may be taken and sent to an independent lab for testing. c. It is the competitor’s responsibility to know what is being put into their fuel cell.
3. Drivers finishing in the top 5 may protest the fuel of car or cars finishing ahead of them. Protest fee is $150. Driver filing protest must have money with them and notify track or series official within 5 minutes of the checkered flag in that event. Fuel sample(s) will be taken and sent to an independent lab chosen by the series for testing. All official’s decisions and lab results are final and official.
4. Penalties for any illegal fuel are as follows: a. First Offense - $500 fine and 30-day suspension from any GCRG sanctioned events and lose 200 championship points. b. Second Offense - $1,000 fine and 90-day suspension from any GCRG sanctioned events and lose 400 championship points c. Third Offense - $2,000 fine and 365-day suspension from any GCRG sanctioned events and lose ALL points for the season. d. ALL OFFICIAL’S DECISIONS ARE FINAL, AND INDEPENDENT LAB USED WILL BE AT SERIES’ DISCRETION.
5. Mechanical fuel pump only. Must be mounted in stock location
Body Rules:
1. Cross Breeding Bodies and Engines: engine manufacturer and body manufacturer may be cross bred (i.e. Chevrolet engine in Ford Chassis and Body, or Dodge or Ford on Chevy chassis and engine).
2. ALL cars must have stock appearing roof. NO flat, late model or open wheel modified style roofs allowed. Roof must have contour/roll in appearance. Roof must have minimum 1” roll/contour – measured from center of roof. Roof can have no more than 1 ½” rake from front to back , and must be level side to side. All roofs must have roof supports both front and rear and should be stock or made just like stock. Cars may NOT run topless. Topless races will not count for points, unless approved in advance by GCRG officials, in which drivers will be given notice. These exceptions will be a rare occasion, or long-standing event, and not acceptable on a regular basis. Remainder of body may be OEM or OEM replacement parts.
3. May use aftermarket body panels. Steel or aluminum hoods, fenders, doors, quarter panels (fenders and quarter panels may be made of composite material), and trunk lids. NO fiberglass side body panels anywhere.
4. ALL bodies must be stock style, have body seams, and look like car being claimed. No “skewing” of body. No raised quarter panels.
5. Sail panels must be the exact same on both sides. This includes size and shape. Sail panels can not mount no further inward than 2” of door/quarter panel.
6. Deck Height: 40” maximum, no tolerance (Body Diagram K). Deck height must be measured from bottom of spoiler to the ground. May be measured at ANY time.
7. Deck Width: 64” maximum. Maximum 5” drop deck below the tops of the doors. Must slope gradually from top of doors to bottom of spoiler.
8. No station wagon, SUV, or hatchback style bodies.
9. Body must not be any wider (from side to side) than 68”, measured at driver’s compartment (see body diagram F).
10. Maximum width at bottom of doors 76” – measured in front of rear tires. (see body diagram F)
11. Rear of car must not exceed 64” wide, measured at top of rear deck (see body diagram G).
12. Rear quarter panels - Both sides of the body must taper inward and the same on each side. No single side taper or “late model” type body taper.
13. Car must have minimum 18” tall, 4” wide numbers on both sides and roof. 6” tall numbers recommended for front and rear of car.
14. All cars must have minimum .080” aluminum cockpit that fully encloses driver compartment. All cars must have front and rear driveshaft loop installed.
15. Passenger side stone shield may go from bottom frame rail to top frame rail and cannot exceed 36”.
16. Aftermarket plastic nose pieces mandatory. The following are the only nosepieces allowed: • Performance Bodies: 1. Monte Carlo- MD3021x410 or PER21x040 2. Camaro- MD365x040 or PER45x040 3. Mustang- MD366x040 or PER46x040 4. Camry- PER47x040 • Five Star: 1. Monte Carlo- 600-410 or 021-410 2. Camaro- 20132-41051 3. Mustang- 20321-41051 • Speedway: 1. Monte Carlo- 91054211 or 91054288 2. Camaro- 9108886 or 9105330 • AR Bodies: 1. Revolution Camaro Nose- 12105-xx **X’s in each part number indicate changes for color options only** NO IROC noses allowed. No plastic skirting or add-ons permitted on bottom of noses. Any additional nose not listed above is subject to approval by GCRG officials.
17. Front of car must be enclosed. NO FLOPPERS OR FENDER SKIRTS ON FRONT END LIKE A LATE MODEL. ALL FENDER ENCLOSURES MUST REMAIN TIGHT WITH BODY LINES AND BE RIVETED TO FENDERS, TUCKED IN TIGHT WITH BODY LINES. Nose pieces should be mounted high and tight like a streetcar. NO wedge or late model style nose pieces allowed. Nose piece and filler panel MUST BE mounted center of the frame/front clip.
18. Width of front fender from side to side – minimum 64”; maximum 66”. Measured from nose mount to front of the door.
19. Tail of car may be completely enclosed or left open.
20. Body must be minimum height of 5” off the ground at all points around car. (Body Diagram B)
21. Maximum distance of 45” from furthest point on front of nose to front cross member (Measured from where lower control arm bolt goes through crossmember to farthest point of nose). (Body Diagram C)
22. Rear Quarter Panels – 48” maximum measured from center of axle straight line to rear of car (Body Diagram D) and 51” maximum measured from center of axle to top of quarter panel/bottom of spoiler (Body Diagram E). Maximum width at the back of the rear quarter panels is 64”, measured at the bottom.(Body Diagram L)
23. Gradual nose rake – 3” maximum (Body Diagram H).
24. No “wings” or gurney lips at any location on the body. A maximum of two(2) roof edge lips with a maximum height of ½” inch. No lexan or metal panels anywhere else unless otherwise stated. Official’s decision will be final.
25. All glass and plastics must be removed.
26. For safety purposes, all cars must have minimum of 13” wide window opening on both left and right side in case of emergency exit (Body Diagram J).
27. Driver cockpit rock shield cannot extend any farther than the front headrest of the seat and no taller than 4” tall maximum. 28. 8” maximum spoiler with 8” side boards (see spoiler diagram for specs).
Engine Option #2 must run 8” maximum spoiler with 8” side boards. Spoiler sides must be in line with body. No skewing of spoiler sides. Must be even with the back of decking. 29. 60” maximum width of rear spoiler (Body Diagram I). Spoiler must be centered on body, and same height, same angle across entire span of rear of car. 30. Bottom of rear spoiler supports must be flush with the rear of the car. Spoiler supports cannot hang or extend off the rear of the car.
Frame and Suspension Rules: 1. 108” minimum wheelbase. Any chassis with wheelbase shorter than 108” will not be allowed.
2. Uni-body cars may connect sub frames. X-bracing allowed. All cars must remain within 1” of stock wheelbase of car being raced. Wheelbase must match that of front clip being raced, and rear suspension must match front suspension (ex. 70s Camaro front clip must have leaf spring rear suspension).
3. Stock frame must remain from steering box mounts to center of rear end and frame rail has to remain in stock location.
4. Crate Racin’ USA X,Y,G Tubular Metric Frame allowed. (Available for purchase by any competitor by contacting Crate Racin’ USA office). All CRUSA tubular frames will be serial/VIN numbered and titled through Crate Racin’ USA. Any tubular frame found to not have the Crate Racin’ USA serial/VIN number will be considered illegal. The only approved aftermarket frame suppliers will be Johnson X,Y,G Chassis and Bernheisel Race Cars M Series Chassis. Either option MUST be certified, and VIN/Serial numbered for use in GCRG competition).
5. Any Crate Racin’ USA Tubular Frame or Repair Clip found to be altered, could result in severe fines and penalties for the racer. The serial/VIN and titling process is implemented to track/trace these from the manufacturer to assist in keeping the program sound and in place.
6. Front Suspension: a. Must use stock type steering box, stock drag link, idle arm. Tie rods and ends may be tubular and made heim jointed. Quick Steer allowed. No adjustable center links. b. Any stock type spindles allowed (recommend Speedway or equivalent 3-piece spindles for ease of repair). No wide 5 spindles or safety hubs. c. Stock production lower control arms, of any manufacture mandatory. Any stamped steel, stock, lower control arm. When utilizing tubular lower control arms, both sides must be +/- 1” of factory length of car being raced. Metric cars may use tubular lower control arms GCRG approved WMP Products Part #1010 or 1110 (Metric/Monte Carlo right side); #1011 or 1111 (Metric/Monte Carlo left side); and #1210 (Camaro/Chevelle right side) and #1211 (Camaro/Chevelle left side) Call (601)527-0084 to order. d. No shortening or lengthening lower control arms. e. 5” or 5 ½” coil springs mandatory, mounted in stock location. No conical springs. f. Weight jacks allowed. g. Tubular aftermarket upper control arms allowed. h. Cross member may not be cut or altered except for fuel pump or oil pan clearance. i. NO bump stops or bump springs of any type allowed. One spring rubber per corner maximum.
7. Rear Suspension: a. Stock type rear suspension only. Must be the same as make of car being raced. b. Stock rear frames may be repaired from center of rear end housing to rear bumper with square tubing or 1 ¾”, .095 minimum thickness round tubing. c. Any stock type rear end housing permitted (GM 10-12 bolts or Ford 9 inch) in any make of car. Rear end may be locked. d. Quick-change rear end optional – must ADD 100 lbs. MUST have steel axle tubes and 10” ring gear. Standard spool (steel or aluminum), no locker. e. Floater axles permitted. f. Must use steel, stock lug pattern hubs. No wide 5 aluminum safety hubs. g. Rear trailing arm mounts at frame or leaf spring mounts, must remain unaltered and in stock location with one mounting hole ONLY. Leaf spring cars may have adjustable shackles on rear only. Rear trailing arms must be stock (may be boxed for strength and safety), or stock length tubular, adjustable trailing arms are ok. Arms must be within ½” of factory length trailing arms for car being raced, 2 ¾” maximum from bottom or rear end housing to center of control arm bolt. h. Upper control mounts maximum of 3” from center of top of rear end housing to center of mounting bolts or on 9” Ford housing, 7 ¾” from seam center of axle tube to center of mounting bolts. i. j. No sliders front or rear. 5” coil spring mandatory. Springs must measure 5” at top and bottom (no conical springs). Any leaf springs allowed. k. Springs must be mounted on top of and centered on axle tube. l. Weight jacks allowed. m. No panhard bars or z bars of any type. n. No underslung rear suspension allowed. o. Bottom shock mount must be mounted behind rear end. p. NO bump stops or bump springs of any type allowed. One spring rubber per corner maximum.
8. Stock Metric frames have the option to be repaired with Crate Racin’ USA tubular rear or front clip (Available for purchase by any competitor by contacting Crate Racin’ USA office) in the event of a crash and needing repair. All CRUSA tubular rear and front clips will be serial/VIN numbered and titled through Crate Racin’ USA. Any tubular rear or front clip found to not have the Crate Racin’ USA serial/VIN number will be considered illegal.
9. Any Crate Racin’ USA Tubular Repair Clip found to be altered, could result in severe fines and penalties for the racer. The serial/VIN and titling process has been implemented to track/trace these from the manufacturer to assist in keeping the program sound and in place.
10. NO bump stops or bump springs of any type allowed. One spring rubber per corner maximum.
11. Solid limiter chains only.
12. Brakes: a. Must have operating brakes. b. Dual master cylinders ok. c. Standard steel rotors only. d. No scalloped or gun drilled rotors. e. Any brake caliper Ok. Brake calipers must be mounted in fixed position. NO brake floaters.
13. No data acquisition devices of any type allowed. Street Stock Aftermarket and Stock Frame Changes Tech Bulletin: 4/18/2025 Recently there have been some questions/concerns regarding changes made to the stock and aftermarket frames approved for use in CRUSA Street Stock competition, and the legality of what changes can or cannot be made to those. After reviewing the approved and non-approved changes and speaking with series tech officials, we are releasing the following bulletin to clarify and clear up the concerns about what is or is not allowed, as well as a short “grace period” to have any car that has unapproved changes be corrected. • Aftermarket frames are allowed to make the following changes only: Johnson version 1 frames are allowed to make right side frame rail straight to match newer version Johnson and BRC frames. Right side replacement frame rail must be square or rectangular tubing. No round tubing. Bottom of the replacement tubing must be flush with the bottom of the existing frame so that the bottom of the entire right side is in the same location as the original chassis was. • Stock frames are allowed to make the following changes only: Stock frame may narrow right rear frame rail for tire clearance (inner portion of frame rail must remain in stock location). • The following applies to ALL Frames: All frames may add strengthening gussets to mounting points such as a-frame, trailing arms, etc. All cars, whether built using the stock frame or aftermarket option, the mounting and pickup points MUST REMAIN IN STOCK LOCATIONS according to the rules. Any deviation in the measurements of the pickup points will render the car illegal according to the rules and will be disqualified. The GCRG Street Stock division is one of the most competitive and exciting racing divisions competing under the CRUSA banner. While the series will shoulder some responsibility in the questions that have arisen, there are instances where manufacturers and teams are making unapproved changes, creating a competitive advantage and causing their cars to fall outside the rules and limitations allowed. We must make the changes and clarifications necessary and public so that everyone knows what is expected, and to remedy any confusion to keep car counts in place and competition on a level playing field. We are taking this very seriously and will be actively checking and assisting tracks in checking to verify that all cars are abiding by the same rules. These clarifications will be strictly enforced beginning May 1st and will be done so going forward. Shock Rule: 1. One shock per corner. Steel bodied, non-adjustable shocks only. Shocks must have solid shaft. No Schrader valve shocks. No piercing valves. Shock valving or gas pressure may not be adjustable at the racetrack. No air shocks. 2. Shock Claim: a. $300 per shock b. Car claiming shock(s) must finish in the top 5 and on the lead lap. Claims must be made to Tech Official within 5 minutes after the checkered flag falls on the feature event. c. No reverse shock claims (cannot claim shocks from car finishing behind you) d. Refusal to allow shocks to be claimed or confiscated by officials will result in driver losing all points and money for that event, and face the following punishment: i. ii. iii. First Offense – 2-week suspension and $250 fine and lose 200 championship points. Second Offense – 30-day suspension and $500 fine and lose 400 championship points. Third Offense – 365-day suspension and $1,000 fine and lose ALL points for the season. 3. Series or track officials may confiscate or claim shocks at any time. If confiscated and shocks are determined to be legal, they will be returned to driver and points and money will be awarded as earned. If shocks are determined to be illegal, driver will lose all points and money from the event and face the following punishment: i. ii. iii. First Offense – 2-week suspension and $250 fine and lose 200 championship points. Second Offense – 30-day suspension and $500 fine and lose 400 championship points. Third Offense – 365-day suspension and $1,000 fine and lose ALL points for the season.
Clutch and Transmission Rule:
1. Automatic transmission with shift kits allowed.
2. Bert or Brinn transmission allowed. NO ball spline Bert or Brinn allowed.
3. Drive shaft loop MANDATORY on all cars. Must be mounted 5” to 8” behind front u-joint of drive shaft.
4. ALL drive shafts must be painted white for safety.
Tire and Wheel Rules:
1. 8” maximum steel wheels. Beadlocks allowed. Stock type lug pattern only.
2. No wide 5 wheels or adapters.
3. Wheel covers must be securely fastened. Recommend that wheel covers have a minimum of 5 mounting points. Wheel covers having only 3 attachment points must be bolted on at all 3 points using a minimum 1/4” or 5/16” magnetic steel hex head bolt and fastening (nut assembly) system. Cars that lose a wheel cover may be subject to disqualification.
4. Hoosier H500 tires American Racer AR 500 and American Racer Stocker Hard
5. No Grooving or Siping (effective and enforced May 1, 2025 forward). No needling. NO drilling.
6. Tires must remain in factory manufactured condition. Any alteration from factory manufactured condition is prohibited. All decisions are final.
7. No chemically altering of tires.
8. Tires must punch 55 at ambient temperature (cold). The series’ durometer is the official durometer and testing method of punch number rule. Any tire failing to punch properly will be subject to further test methods and disqualification. Tire(s) in question may be confiscated and tested by any means deemed necessary by track or series’ officials. All decisions are final.
9. Drivers finishing in the top 5 may protest the tire of car or cars finishing ahead of them. Protest fee is $150. Driver filing protest must have money with them and notify track or series official within 5 minutes of the checkered flag in that event. Tire samples will be taken and sent to an independent lab chosen by the series for testing. All official’s decisions and lab results are final and official.
10. Penalties for illegal tires: a. First Offense - $500 fine and 30-day suspension from any GCRG sanctioned events and lose 200 championship points. b. Second Offense - $1,000 fine and 90-day suspension from any GCRG sanctioned events and lose 400 championship points c. Third Offense - $2,000 fine and 365-day suspension from any GCRG sanctioned events and lose ALL points for the season. d. ALL OFFICIAL’S DECISIONS ARE FINAL, AND INDEPENDENT LAB USED WILL BE AT SERIES’ DISCRETION. e. Failure to allow any tire(s) to be confiscated will result in an additional $500 per tire fine added to any other fines and penalties. All decisions are final.
Fines, Penalties, and Suspensions:
1. Pre-Race Technical Violation(s): Any technical violation(s) discovered during pre-race technical inspection, the driver will be notified of violation(s), and car must be fully in compliance before allowed to compete.
2. Legality of Part(s): Any question concerning legality of part(s) by GCRG or track technical inspector, the part(s) in question will be confiscated and sent to Chevrolet Performance or GCRG for further inspection. The finish for this race will be held until legality of part is determined. Points, monies, and finish will be adjusted in the event of a disqualification. Any parts deemed illegal will be confiscated. Failure to allow confiscation of any part will be penalized the same as an inside the sealing system engine infraction and penalized accordingly (see Engine Option #1 Penalty #1).
3. By entering and/or competing in any GCRG sanctioned event, drivers, car owners, and team members waive any right to file an appeal. All official’s decisions are final.
4. All decisions of series officials and/or the promoter regarding the application or interpretation of the rules, and the scoring of finishing positions shall be non-litigable. All participants agree that they will not initiate any legal action against GCRG the promoter, or officials to challenge any decision, to seek monetary damages, to seek injunctive relief, or to seek any kind of legal remedy. Any such legal action pursued by a participant which violates this provision, the participant (driver) and/or owner expressly agrees to reimburse GCRG for all its attorney fees and costs in defending against such legal action.
5. By signing the annual membership/registration agreement, participants agree that they will comply with the written rules and procedures of GCRG. If the participant breaches this membership/registration agreement, he or she will be liable for actual and liquidated damages sustained by GCRG
Code of Conduct and Conduct Penalties:
1. Drivers, car owners, and teams are to always conduct themselves in and orderly and professional manner while competing at any GCRG sanctioned event. Series director will judge incidents of conduct accordingly and use the following criteria to assess any penalties upon a driver, car owner, or race team as necessary.
2. Driver will be notified of penalties that have been levied by the series director. All series director’s decisions are final.
3. Series director may choose to levy monetary fines, suspension from sanctioned events, and deduct points as deemed necessary by the rules infraction or actions taken by a driver at any time. Series and tracks reserve the right to enforce or levy fines, points penalties, require changes, or suspension from competition for any actions deemed detrimental to the sport, series, or track. This includes, but is not limited to, social media posts, and/or derogatory or distasteful statements/slogans/photos/graphics on cars or any other driver-related material visible to the public (i.e. helmets or driver’s suits, trailer or transporter, etc.).
4. Series will adhere to, and uphold any suspension levied on a driver by a specific track. If a driver has been suspended or barred from entering the property, that will be upheld by the series. Series and sanctioned event do not overrule a track’s decision to refuse entry to any driver, car owner, or crew member.
5. NOTE: These rules are not intended to eliminate competition or accidental contact. However, they are intended and may be used to penalize deliberate contact and/or over-driving or deemed deliberate acts of aggression towards other drivers.
6. No driver will be allowed to compete/participate while under the influence of any alcoholic beverage or illegal/controlled substances. If a driver is found to be participating in such a manner, that driver will be immediately suspended and removed from competing.
7. Any competitor that verbally abuses a series or track official by using profane and/or disrespectful language is subject to a fine of $100 for the first offense. A $300 fine, one-race suspension, and loss of points for the second offense. After a second offense, driver is subject to 30-day or longer suspension and loss of points as determined by officials.
8. Any physical confrontation, either on the track or in the pit area, will result in the aggressor(s) being suspended for one race, loss of points, and $300 fine for the first offense. A second offense will result in the driver being suspended for the remainder of the seasons, and a $500 fine.
9. Any driver who enters another driver’s pit area, or approaches another driver’s car on the speedway, will be deemed the aggressor. Away from either driver’s pit area, both drivers will be considered aggressors. Drivers should be aware that they are responsible for any member of their race team, and the above penalties will apply to the driver concerned even if the driver is not directly involved.
10. In the event of a felony conviction of a driver, team member, or team sponsor, disciplinary action could be a minimum of a 365-day ban from the series beginning with the date of the conviction or the date of the completion of any incarceration to said conviction, whichever date shall last occur.
11. Disciplinary action may also include, but is not limited to, the right of the series organizers and officials to suspend either temporarily, or permanently, any driver, team member or sponsor, whose actions, in the sole opinion and discretion of the series organizers and officials, may have resulted in, or may result in harm or detriment to GCRG.
12. Any incidents occurring during the last five events of the season, may result in penalties being applied to the beginning of the following season.
13. Any incident(s) that are judged to be deliberate acts of aggression, whether on or off the track, under green or caution, will result in disqualification and a monetary fine to be determined by series’ officials.
14. Series officials reserve the right to increase the above penalties, by either adding additional money, suspension time, or points loss, depending on the severity of the incident.
15. Series officials reserve the right to revoke a competitor’s membership at any time. All official’s decisions are final.
16. Any threat of, or legal action taken or levied against the series by a driver/race team, will immediately result in that driver’s indefinite suspension from competition in any/all Crate Racin’ USA sa
Gulf Coast Racing Group
2026 FACTORY STOCK RULES
These rules are to tell you what you can do. If it is not in the rules and you do it, it is NOT LEGAL unless cleared by tech-inspector.
The Statement: Unless it came on a stock, mass produced vehicle, it is NOT LEGAL UNLESS SPECIFIED HERE! If it came on a stock, mass produced vehicle and it is prohibited here, it is NOT LEGAL! All dimensions are referenced as the car is raced. Your tire pressures, spring settings, etc. May put your car out of limits. No variances are allowed when / if the cars are checked / weighed going onto the track.
Following the race, decisions on variances for accident is at the discretion of the Tech Inspector(s).
RELATIONSHIP TO OTHER CLASSES:
These cars are primarily for NEWER drivers to V8 cars.
ELIGIBLE MAKES/MODELS:
Any Chrysler, Ford or GM model car that was / is mass-produced for the United States Market. Check with track before you build.
MATERIALS:
No ceramic or carbon fiber parts allowed.
RADIATOR:
One, mounted in front of the engine for the purpose of cooling water and, optionally, to cool an automatic transmission.
ENGINE:
Location: Stock location for Make / Model / Year.
Option 1
The ONLY aftermarket seals allowed for competition are:
a. GM twist off bolt engines will NOT be legal.
b. Chevrolet Performance cap seals
c. Crate USA Gen IV(Green) or Gen V(Black) cable seals, RUSH cable seals, IMCA cable seals allowed.
d. NOTE: Crate USA Gen V (LIGHT BLUE) Seals are allowed. These seals will begin with number 406XXX. e. NO ACAS, NDRA, FASTRAK, Crate USA Gen I (Silver), Gen II (Blue) or Gen III (Yellow) will be allowed. f. To compete with ANY other seal/sealing system contact GCRG for approval.
If Bolts or Seals are altered, you will be DISQUALIFIED. (Must run 500cfm Holley 2 barrel) If you put a 602 Crate Motor in any other chassis besides GM, contact Tech Man for engine location.
Option 2
BLOCK: Stock based, steel, small block not to exceed 364 ci. No 400 ci engines Must be stock bore (+60 okay) and stroke. NO stroker / hybrids (No 383ci Chevys, No 347 Fords, ect.) All engine casting numbers stamped on the engine must be unaltered.
CAM: Chain driven. HYDRAULIC OR SOLID ; NO MORE THAN 450 LIFT MEASURED AT INTAKE
LIFTERS: Solid or hydraulic. No rollers or mushrooms. No ceramic.
PISTONS: Dished or Flat top onlyb . No Domes.
RODS: OEM length. Example: SBC must be 5.7” I-Beam Rods No 6” rods. No H-Beam rods. May use aftermarket part numbers only SCAT # 2-ICR5700 OR EAGLE # SIR5700BBLW OR STOCK GM NO HBEAM OR LIGHTWEIGHT RODS
HEADS: OEM iron heads. Vortec heads okay, Vortec copy okay. Not to exceed 173 intake runner volume.
No Porting or Polishing. OEM style stamped steel rockers. No roller rockers. No roller tipped rockers. Screw in studs and guide plates OKAY. No Porting/ Polishing.
VALVES: Maximum of 2 valves per cylinder. Max intake is 2.02. Max exhaust is 1.600.
CARBURETOR: One carburetor 500 cfm two barrel Holley with stock, unaltered, throttle arm and butterflies. Choke plate may be removed. No Porting or Polishing. MUST PASS GO/NO GO gauge. The accelerator pump squirters may not extend into the area directly above the venturi (Tech Purposes).
Recommend Epoxing the boosters for safety. MUST HAVE CHOKE HORN No 4412C,4412CT,4412HP
Holley Ultra XP series carburetors “polished aluminum type with choke horn omitted”
CARBURETOR CLAIM: Any car owner of a car in the FEATURE RACE may claim the carburetor of any car finishing ahead of the claimers car, in the FEATURE RACE for $300 and swap of claimers carburetor. Only 1 Claim per year. (Tech Inspector(s) will have final say so if carburetor is in shape to swap).
INTAKE MANIFOLD:
No Porting / Polishing. OKAY to drill the intake, to mount on Vortec heads. Any cast iron or aluminum intake. Dual Plane Intake ONLY.
CARBURETOR ADAPTER / SPACER:
No more than 1 adapter and no more than 1 spacer, a combined total of 1” thick. May be Aluminum, Wooden or Plastic. Cannot extend into manifold.
AIR FILTER HOUSING:
No vacuum lines allowed between the air cleaner and the carburetor. Only one, round, mass produced air cleaner may be used. Maximum size of the element will be 14” in diameter by 4” tall. Air cleaner top and bottom must be made of solid metal. NO PLASTIC AIR HATS.
IGNITION:
Battery operated. OEM electronic ignition system such as HEI required. Distributor must be mounted in the stock location and maintain the stock firing order. No crank / triggered ignition. No ignition boxes.
CRANKSHAFT:
OEM crankshaft or OEM replacement cast or steel crankshafts only. Scat #9-10442, Scat #9-10526, Eagle #103523480, Stock stroke. No lighting, no knife edge, no polishing. Must Weigh 48lbs without gear
ALTERNATOR:
If used, must be 12 volt and of OEM design.
HARMONIC BALANCER:
After market to include fluid damper okay.
NUMBER ONE PLUG:
Must be at stock location for make and model. Engine has to be in stock location on frame. ZERO ENGINE SET BACKS.
STARTER:
Full size or Mini Starter okay. MUST HAVE STARTER.
WATER PUMP:
After market okay.
POWER STEERING PUMP:
Stock location. : After market power steering pumps and steering quickeners are okay.
ACCESSORIES:
Other items must be OEM style but may be after-market items.
PROHIBITED:
Any titanium or other similar sophisticated lightweight parts. Mounting the engine so that the centerline of the crankshaft is more than 1” from the center point between the 2 top ball joints.
FUEL:
Racing gasoline OKAY. NO E 85. No aftermarket additives. No cool cans. See the safety rules on the required fuel cell.
EXHAUST:
Must exit approximately parallel to the ground and not be aimed in the direction of the cockpit. Headers OKAY with 1 5/8 inch primaries and 3” collectors. No over the frame or crossover headers. Turndowns recommended.
FLYWHEEL/FLEXPLATE:
OEM steel only. OEM dimensions
CLUTCH/TRANSMISSION:
Single disc clutch only 10 1⁄2” minimum. No aluminum flywheel. Stock type flywheel to weigh no less than 14lbs., stock type pressure plate no less than 13lbs., stock disc type clutch and flywheel required. Stock torque converter 11” minimum required with automatic transmission. Transmission may have shift kit installed, 1⁄4” steel plate surrounding stock bell housing or blow proof bell housing required. No racing clutches are light flywheels, or small torque converters, or racing torque converters are allowed. Functioning torque converters must weigh 38lbs minimum.
DRIVE SHAFT:
OEM steel. Universal joints are to be similar in design to OEM units.
REAR END:
Ford 9” OKAY in any make. When using 9” Ford make sure brackets are 3” maximum from bottom of rear end housing to center of control arm bolt. Must be the same both sides . . IF any questions about stock location, call track BEFORE you weld brackets on. OEM 5 or 6 lugs OKAY, consider installing C-Clip eliminators or other provisions such as that breaking a rear axle does not cause the axel to come out of the housing.
BRAKES:
Minimum of 2 rear and 1 front brake. No floating brakes.
Dual Master Cylinder OK. No Brake Bias.
BATTERY:
May use 2 batteries. If battery is located in drivers compartment it must be in an enclosed battery box and securely fastened. No bungee cords or ratchet straps. NO EXCEPTIONS. Must power the starter and the ignition and any accessories.
CHASSIS:
OEM for Make / Model / Year of the body.
WHEEL BASE:
Must be as manufactured for the Make / Model / Year. Minimum Wheel Base 108”. A one-inch tolerance may be allowed at the direction of the Technical Inspector for accident damage the day of race.
STEERING:
OEM style for Make / Model. No Rack and pinions unless OEM Equipped.
SHOCKS:
***** effective 2021*****
Steel body shocks, stock mount, non-adjustable shocks. No heim ends allowed $300 shock claim rule.
The $300 claim is for all 4 shocks and claiming car must be on the lead lap. Can only claim or be claimed once in a season. May run shock extension on left rear ONLY
FRONT SUSPENSION:
Upper A-arm and all steering linkage may be reinforced as long as their identities remain clear. Factory spec upper control arms with lengths of eight (8) inches or eight and one-half (8.5) inches are permitted. Upper A frames must be within one inch of OEM offset. May use stock dimension tubular upper A-Arms must be mounted in stock location on chassis. OEM style and dimensions racing shocks allowed. Aftermarket ball joints are permitted but must be stock OEM dimensions. Rebuildable ball joints are permitted. Upper ball joints may be any height but must be in the stock location.
Shocks MUST use the OEM mounts and remain in their OEM location. NO SCREW JACKS. No Bump Stops or Shock Covers. NO SPRING RUBBERS. NO SPRING BUCKETS. NO CHAINS, NO CABLES, or NO TETHERS allowed anywhere on chassis or suspension. No adjustable spring spacers must be solid or welded off
OEM style and dimension racing springs allowed. Springs must remain in their stock mounts and locations. For coil spring cars you may use 5” springs. Chrysler torsion bar suspension is permitted if it was stock on the year and model designated for the car. No driver adjustable suspension devices permitted. Spindles “3piece Spindles” and lower control arms MUST BE STOCK to the chassis being used. Also, upper control arms, spindles and lower control arms must be in STOCK LOACTION for chassis being used. NO limiting of suspension up or down
REAR SUSPENSION:
OEM. Shocks must use the OEM mounts and remain in their OEM location. NO SCREW JACKS. No Bump
Stop or Shock Covers. OEM style and dimension racing springs allowed. NO SPRING RUBBERS. . NO CHAINS, NO CABLES, or NO TETHERS allowed anywhere on chassis or suspension. Springs must remain in their stock mounts and location. Center bolt of the Lower Rear trailing arms cannot no more than 2.5 inches from the bottom of the axle tube must be even For coil spring cars you may use 5” springs. Chrysler torsion bar suspension is permitted if it was stock on the year and model designated for the car. OEM design leaf spring setups in which the springs are securely fastened to the rear end are OKAY. No driver adjustable suspension devices permitted. No “Z” links, aftermarket pan hard bars, aftermarket Jbars, torque links, torque arms, damper shocks, fifth coils, ECT. NO limiting of suspension up or down SPRING BUCKETS O.K. SPRING MAY NOT EXCEED INTO BUCKET MORE THAN ¾ OF A INCH FROM THE FLAT PART OF THE ORIGINAL SPRING PERCH
Adjustable spring “bucket/cup” can used ONLY on the left rear upper or lower . Right side may NOT have any spacers or adjustments.
TRACTION CONTROL:
Other than listed under REAR SUSPENSION, no other traction devices are permitted.
BODY:
MUST HAVE COMPLETE BODY
OEM production body or sheet metal body OKAY MUST LOOK STOCK APPEARING (WE WILL NOT LET THIS GET OUT OF HAND). Complete stock body, unaltered except as stated here. Hoods may be gutted.
Firewall can be stock or fabricated and must be in the stock location. No open holes in firewall (seal Penetrations). Maintain the floor from firewall rearward to the leading edge of the trunk. There must be a firewall between the driver’s compartment and the trunk. Car must be sealed at the back of back seat frame work. floor pan and fire walls can be fabricated with the same thickness of steel as stock “ 20 gauge “ and must go from stock frame rail to stock frame rail no aluminum NO decking allowed, must have open cockpit from firewall to rear firewall. All doors must be welded and / or bolted shut. Doors may be gutted. Install 3 driver’s sidebars, with 1/8” steel plate covering the door bars from front to back and top to bottom welded in place on outside of bars (Strongly Recommended). Install a minimum of 2 right side bars. The frame rails do not count as the door bars. See the safety rules for other items. Front inner panels optional on shock cars, required on strut cars. Trunk lid may be gutted. All glass must be removed. No mirrors. Grill may be replaced with wire mesh. Must have stock bodylines. Must have a metal firewall between driver and fuel cell. No fuel line in driver’s compartment unless contained in conduit / pipe. Fenders may be cut for tire clearance. Front fender well may be removed. The rear of the car must be closed in with either a aftermarket tail piece or metal. If Metal must go form top of frame to to of deck. May leave open 10” on each side. Rear of car must have downward slope from back of rear glass to back of trunk lid Rear deck height 40"on hung bodies (minimum 35") CAN BE MEASURED ANY TIME NO TOLERANCES
NOSE / GRILL:
Aftermarket plastic nose for Make / Model OKAY. Front grill may be removed if such nose is installed. MUST Match Body/ Year Model.
Hood:
May have an opening for the air cleaner. The claimed engine size must be displayed on each side of the hood reading from the closet side of the car. Use letters at least 3” tall with the length proportional to the height.
ROOF:
Stock appearing. The left and right edges of the roof are to be approximately the same height from the top of the doors and quarter panels. No more than 1” tolerance. The left and right side support panels for the roof must be the same design and front to back length.
INTERIOR:
See the section on SAFETY.
No part of the seat may extend rearward past the plane generated by connecting the rear most edges of the doors. Aftermarket GAS pedal OKAY. (May be relocated). Must retain OEM window openings.
TRUNK LID:
Required. May be gutted. Must be able to be opened. May Run 3” spoiler max
REAR BUMPER:
Any Make / Model OEM OK. Fabricated OK if approved by Tech. Ends must be smooth. Must be attached to the frame or roll cage in at least 4 places, 2 on each side of centerline.
WHEELS:
15X8 Steel wheels only. No wide fives. Must mount with at least 5 lug nut design. Mud caps OKAY. Bead Locks may be run in any location.
TIRES:
Hoosier H500 or American Racer Stocker HARD or American Racer AR500 Xtra hard or 60 Series Radial D.O.T. NO MUD GRIPS. Grooving and Sipeing OK NO CHEMICAL ALTERATION ON TIRES.
WEIGHT:
All cars must weigh 3200 pounds with driver on board. No Fuel Burn off
ALL BALLAST MUST BE PAINTED WHITE AND HAVE CAR NUMBER ON IT
ABSOLUTELY NO BALLAST CLAMPED OR BOLTED TO THE REAREND HOUSING
PROTEST:
Protestor must be in top 5 finishing the feature race
Protest is only for one item that you as the protestor is claiming.
Tires 500.00 Track retains 250.00
Suspension 1000.00 Track retains 500.00
Upper Engine 1500.00 Track retains 500.00
Lower Engine 1500.00 Track retains 500.00
IF YOU FEEL YOU NEED TO TEST THESE RULES, MAY BE YOU SHOULD START IN STREET STOCK. GOOD LUCK IN POST RACE INSPECTION
NOTE: Any interpretation or deviation of these rules is left to the Mitchell's Motorplex officials
Any decision of and by Mitchell’s Motorplex officials is final. Any unsportsmanlike conduct can carry a minimum $100 dollar fine and/or suspension.
Car must meet satisfaction of chief technical inspector for integrity and safety each night before allowed on the racetrack.
DISCLAIMER
The rules and regulations set forth are designed to provide for the orderly conduct of racing events and to establish minimum acceptable requirements for such events. These rules shall govern the condition of all events and by participation in these events, all participants are deemed to have complied with these rules.
The minimum requirements set forth may change at the discretion of the management of Deep South Speedway.
No expressed or implied warranty of safety shall result from publication of or compliance with these rules and/or regulations.
They are intended as a guide for the conduct of the sport and in no way guarantee against injury or death to a participant, or any other individuals that enter the property.
RACING IS A DANGEROUS SPORT. PARTICIPANTS AND ALL OTHERS THAT ENTER by Mitchell’s Motorplex PROPERTY CAN BE SUBJECTED TO INJURY OR DEATH. YOU ASSUME YOUR OWN RISK AND RESPONSIBILITY WHILE ON MITCHELLS MOTORPLEX PROPERTY.
Anything not specified must be OEM and remain in stock location with no modifications.
Any interpretation or deviation of these rules is left to the chief technical inspector, any decision of and by Mitchell’s Motorplex Officials is final.
1. RACECIEVERS ARE MANDANTORY!
2. ALL CARS MUST HAVE TOW CHAINS on front and rear of car, easily accessible to track officials.
3. No driver may get out of his/her car on the track or infield to argue or discuss the race with officials. If this rule is violated the driver may be disqualified and/or fined for the event and/or future events. ALL drivers are responsible for their crew members and their actions.
4. The speedway is private property. Through your admission ticket you have been given the right to be on this property in conjunction with racing activities. However, the management of the speedway reserves the right to revoke and cancel this right at any time that it is felt that your presence or conduct is not in the best interest of the sport of auto racing, your fellow competitors, the fans or management of the speedway.
IF IT DOESN'T SAY YOU CAN - YOU CAN'T
Bodies & Frames
1. 1969 or newer.
2. 4 point cage minimum with 3 door bars on each side – May run Full Cage. All welds and structural integrity must be satisfactory of chief technical inspector. Vent bars on both sides of the car measuring no less than 10” in length with minimum .095 thickness, 1 1⁄4” round tubing.
3. All glass must be removed.
4. All body parts must remain stock except rear bumper may be replaced by 2×2, 2×3, or round tube but must be extended no further than 5′′ from frame rails. No pointed or sharp edges of any kind. No solid stock. Rear bumper must be capped off at the ends.
5. Frame must remain complete and unaltered.
6. May skin car with sheet metal, may be aluminum (.040 minimum) or steel (24 gauge). Must retain factory steel roof panel. Must retain factory body lines for car being run. Sail panels must appear stock, no exotic panels. It must appear stock. No spoilers or side spoilers allowed. Hood must measure no less than 46” width, and 46” length. Trunk must measure no less than 44” width and 30” length. The body must be the same width across the front and the rear. All holes in firewall and floor pans must be sealed. Hood and trunk panels may be aluminum.
7. Minimum roof height is 53" and 58” max. Must measure same at front and rear of the roof panel. No sloping or angling of the roof, must appear stock.
8. Maximum distance from firewall to back of seat 59".
9. Monte Carlo nosepiece only, 78-86. Must be mounted upright like stock.
10. Back must be enclosed. May use aftermarket tailpiece.
11. Minimum door opening 13".
12. Must have stock roof.
13. Rear deck from speaker platform to back of seat may be sloped to seat bottom.
14. No boxing of interior.
15. Rear deck height 40"on hung bodies (minimum 35")
16. No more than 3" fall from firewall to rear of nose piece.
17. Unibody cars must tie sub-frames together in a manner that is acceptable to track officials. 18. May run aftermarket Camaro nosepiece on Camaro chassis.
Tires & Rims
1. 8 inch wheel maximum width.
2. Towel City Yellow Dot tires only, all 4 tires.
3. 1′′ Lug Nuts Mandatory.
4. Bead lock wheel on right rear only.
5. 2" or 3" offset.
6. No wheel spacers.
7. No tire alterations of any kind allowed (chemical or physical). Automatic disqualification.
Rear End
1. Locked, limited slip, or shimmed ok.
2. Rear-end must be for make and model of car being used.
3. Aftermarket axles are recommended.
Suspension
1. No modifications allowed
2. Stock diameter springs only , may change rate, no screw type adjusters. no racing shocks. 3. No adjustable spring spacers allowed, must be solid.
4. NO Sway bar.
5. Solid spring spacers ok, no adjustable screw type adjusters allowed.
6. Steel aftermarket upper “A” frame allowed. Non adjustable. Stock length. Stock type ball joint of stock length. No screw in ball joints. Right front uppers must be 8”, left must be 8 1/2”.
7. . Stock mount steel body Racing Shocks will be allowed starting in 2020 no take a part shocks allowed.
Rebuildable and adjustable type shocks will not be permitted.
8. Must have WORKING FOUR WHEEL brakes.
9. Four-wheel disc brakes OK. No Aluminum brake parts. No Scalloped rotors.
10. Single brake master cylinder only. No brake adjustments of any kind. No valves of any kind. No regulating of brake pressure of any kind (other than the drivers foot). Brake lines must be routed in a manner in which the complete length of line may be inspected by track officials.
11. Three-piece spindle ok- IMCA/Speedway STAMPED. No short arm 12. No suspension binding of any kind via chains, cables, etc. Suspension must be able to move freely.
13. No internal or external bump stops on shocks.
14. May change rate of leaf springs. Must mount in stock location. Mono leaf not allowed.
15. No sliders on leaf spring cars. Spacing Blocks allowed but cannot be wedge or adjustable.
16. Front frame must match rear frame
***SHOCK CLAIM*** effective 2020
1. Any eligible driver finishing feature that is scored on the lead lap can claim all shocks for 300.00 from any of the top three drivers.
2. Only driver may claim and agree to sell or refuse. In case of multiple claims on same item, drawing will be held to determine outcome. Claim is not charged to drivers not awarded item. If first eligible driver withdraws claim, next eligible driver will be awarded claim.
3. Driver must report the claim to the Chief Technical Inspector IMMEDIATELY after the feature race and must have CASH in hand.
4. All claimed items must be removed at the track, within a reasonable amount of time (at discretion of track officials) and must leave the track under possession of claiming driver. If any driver is caught at the track claiming for another driver, both drivers forfeit all cash, trophies and contingencies for event.
5. During a claim, all shocks should be inspected for legality prior to transfer of items. If claimed item is found illegal, driver is disqualified. Claimer then has option to accept or decline claim.
6. Refusal to sell any claimable item forfeits all cash, trophies and contingencies for event.
Gas Tank
1. Fuel cell recommended, must be mounted in the center of the car.
2. Fuel lines must be routed so they cannot be ripped loose from racing action. If ran through interior of car, they must be in conduit or other protective metal casing. They must be insulated in protective casing from fuel cell to fuel pump so that the fuel line may not be damaged in competition.
3. Fuel cell must be mounted in can with two 2′′ straps top and bottom. Must have tip over valve.
4. Fuel Cells will be only 16 gallons. No larger than 26x19x13, and no thicker than 18 gauge metal.
5. Gasoline or racing gas ONLY. No Methanol or Alcohol. No Nitrous Oxide. No Propylene Oxide. No Methanol or Alcohol. No Nitrous Oxide. No Propylene Oxide. No Nitromethane. No MTBE. No E-85.
General
• ANYTHING NOT SPECIFIED IN THESE RULES MUST BE STOCK, IN ORIGINAL POSITION FROM ORIGINAL MANUFACTURER.
• All parts must have stock casting numbers.
• c.1969 or newer American made 2 or 4 door sedans with a minimum wheelbase of 108”. Frame and body must match.
• No front wheel drive cars.
• Engine must be used for make of car used, year may be interchanged.
• Stock style Moroso mounts or pedestal are allowed.
• Cross member must remain unmodified. A-arm mounts must be in stock location.
• Breather and full air filter required at all times. No air boxes.
• Stock unaltered turbo 350 or 400, metric 200 transmission only. Stock and unaltered torque converter 11” minimum. Torque convertor cannot weigh no less than 30 lbs when removed from the transmission.
• Battery must be mounted and secured in rear trunk compartment or in the front engine compartment area.
*No Batteries allowed to be mounted inside drivers compartment area unless in a sealed marine style box * •Steering quickener or aftermarket steering box ok
Engine
1. No aluminum engine parts.
2. Unmodified Holley part #4412 only. No modifications except choke butterfly and shaft may be removed. Choke horn must remain unmodified. Maximum 1” aluminum spacer/adapter with 1 gasket per side not to exceed .065”in thickness.
3. Unmodified cast iron 2 or 4 barrel intake manifold must be factory OEM stock. Must be factory low-rise OEM stock. No bowtie, aluminum, airgap, or marine intakes. No GM 14098242 or GM 14096242 intakes. No porting, polishing or milling allowed on any intake.
4. Headers allowed, part number SUM-G9005 or Flotech 11108FLT and Schoenfield 185 . No center dump manifolds. No crossover or “H” pipes. Exhaust must extend past driver on the short tube headers Maximum id on pipe is 1-7/8” inch. , exhaust pipe extension past driver will not be mandatory on Schoenfeild part# 185 header must have turnouts 5. No phenolic/wooden carburetor spacers.
Cylinder Heads
1. Stock production heads only and must be for 350 engine only. No closed chamber heads, no aluminum heads. No Vortec heads. No angle plug heads. The following heads are not allowed (last 3 casting#s) 040, 041, 186, 291, 292, 461, 462, and 492. Any questionable heads must be approved by chief inspector prior to racing. #EQ CH-350i Cylinder Head with 1.94 intake, 1.50 exhaust valves.
2. Maximum compression 165 lbs. (+10) with exhaust valve disabled, all plugs removed, and carburetor in full open position with a battery charger if needed. Time limit may be enforced by chief tech inspector.
3. No flow work on heads, no port matching, no angle milling.
4. Stock diameter (1.25 in) valve springs. No beehive springs. No over sized valves, max size is GM 1.94 intake 1.50 ex. Ford 351w & 302 2.02 intake and 1.60 ex. 3 angle valve job ok. No angle milling allowed.
5. Stock rockers, stock ratio only GM 1.5 ford 1.6 6. Screw in studs and guide plates ok. No stud girdle .Poly locks ok.
Block
1. Block may be bored max .060”over maximum 360 cid.
2. Stock production rods only. 5.7 only must have factory markings. Must be stock length for engine being used. May use aftermarket part numbers only SCAT # 2-ICR5700 OR EAGLE # SIR5700BBLW OR STOCK GM NO H-BEAM OR LIGHTWEIGHT RODS
3. No dome or pop up pistons. Aftermarket dish , flattop 2 or 4 valve relief pistons ok.
4. 4. OEM crankshaft or OEM replacement cast or steel crankshafts only. Scat #9-10442, Scat #9-10526, Eagle #103523480, Stock stroke. No lighting, no knife edge, no polishing.
5. Aftermarket oil pan ok. 1” inspection plug welded in oil pan 5” from front seal and 1 1⁄2” down from pan rail on drivers side. Should be between second and third pan bolt. Should not be obstructed by windage tray. Must be able to remove at the track for inspection purposes.
6. Aftermarket hydraulic camshaft allowed. Maximum lift .284”measured at the cam. Cast crank 47 lbs. minimum and steel crank 50 lbs. minimum.
7. Firing order must remain stock and unaltered, No 4-7 swaps
8. Aftermarket aluminum radiator ok.
9. Any water bottles or other cooling devices must be securely mounted on right side of car and forward of the rear- end.
10. Aftermarket power steering pump and aluminum pulleys ok.
11. Aluminum water pump ok.
Safety
1. All cars must have 5-point approved safety belts mounted by 3/8 grade 5′′bolts. 3” minimum strap width and must be manufactured within 3 years of event.
2. Approved helmet and goggles or shield. Helmet must be SNELL approved.
3. Driver’s fire suit required. Must be complete!
4. Working 2-1/2 lb. minimum fire bottle required properly mounted within reach of driver while securely seated. May not be hose clamped, taped, zip tied, etc.
5. Use a properly installed racing seat and fuel cell for safety purposes. These items will be checked for proper installation prior to going on the track by Tech personnel.
6. Drivers neck brace is mandatory.
7. Roll bar padding is mandatory on all bars within reach of any part of the drivers body while driver is properly seated in the car.
8. Drivers window net manufactured within past 5 years is mandatory.
9. Ribbon type window net only. No sprint car type or mesh.
10. Must have protective bars in windshield area forward of driver.
11. Absolutely no weight or ballast added to the car of any kind. No over sized, high gauged, or solid stock frame alterations or bumpers.
MUST START ALL RACES WITH HOOD,ROOF,TRUNK LID,FENDERS, DOOR AND QUARTERS IF YOU HAVE A BODY PART DAMAGED DURING RACING ACTION BEYOND REPAIR PLEASE SEE THE TECH INSPECTOR BEFORE YOUR FEATURE OR HEAT RACE
Gulf Coast Racing Group
General:
1. Must be a commercially produced FWD 4-cylinder car.
2. No turbo charged, super charged or rotary engines allowed.
3. No all-wheel drive cars or all wheel steer cars, unless rear drive shaft has been removed and/or the rear steer has been immobilized.
4. Engine must be outwardly stock appearing. There is no engine teardown or protest.
5. Engine must match brand of car (ex. Honda must have Honda engine). Engine swaps are allowed.
6. Track official has final ruling on all questions of legality. A pre-race inspection will be made to ensure safety only.
7. Questions of legality can and will be answered during the pre-race inspection if asked by entrant. No guarantee of legality shall be expressed or implied during pre-race inspection. Legality will be determined in POST-race inspection.
8. Competitors must present cars for inspection prior to participating in any racing event.
9. Mirrors are not allowed
10. RaceCeiver or a like device is mandatory at all times on track.
11. No two-way radios of any kind allowed. Any team caught using two-way radios will be subject to disqualification and suspension.
Weight:
1. All cars must weigh a minimum of 2,200 pounds with car and driver after the race.
2. Exceptions: 50 lb. weight break for HANS or like device. 50 lb. weight break for full containment seat.
3. Ballast or Lead Must Be painted White with number inscribed
4. Must be mounted to a roll cage bar not a body panel.
Suspension:
1. Must have stock rear and front suspensions as from factory. Any transplanted OEM suspension or steering parts must be brand for brand and must bolt into factory mounting holes without alteration to operate. Slotting of factory mounting holes allowed.
2. No adjustable aftermarket suspension components. Any adjustable OEM components must be welded to render them non-adjustable Plating and structuring for durability and safety is allowed.
3. Strut towers may not be moved from original OEM position – they cannot be cut off and replaced. Minimal repairs are allowed.
4. No racing springs/shocks/struts allowed. Springs may be heated, clamped or use spring rubbers. Springs may be swapped from other models but within 2” of factory installed height.
5. Rear control arms should be stock but may be braced, strengthened and/or repaired. No adjustable
6. Stock type aftermarket suspension bushings are allowed
7. Stock-type standard, non-adjustable, non-rebuildable shocks / struts required.
8. No weight jacks / cups of any kind.
9. Suspension limiter chain or tether is allowed as a solid piece. No aftermarket limiters.
10. Bump stops are allowed on struts.
Body / Roll Cage:
1. Must have a fully-welded, quality built minimum 4-point roll cage inside the car with minimum of 0.95" thick tubing. Track official has final say in safety of the cage.
2. Minimum 3 driver door bars / 2 side door bars – 6 or more-point cages okay
3. Minimum of 3 vertical windshield or “trash” bars in front of driver.
4. No part of the driver’s helmet may extend above the lower level of the roll cage halo.
5. Roll cage may extend forward behind bumpers. Bumpers must be covered with minimum of 8” width plastic or factory/aftermarket rear bumper cover with no exposed sharp corners. Coverage is at the track officials discretion.
6. Frame-like tubing only allowed for repairs in front of front strut towers and behind rear strut towers. No other frame-like tubing may be added to chassis.
7. Aftermarket nose pieces allowed. Any nose piece used must be conformed to fit at reasonable and near-factory dimensions. Overly wide nosepieces will have to be trimmed as per track officials discretion.
8. No push bars to extend outside of bumpers or beyond nose piece.
9. All bumpers (stock or tubing) must be covered and no sharp edges may be exposed
10. No rub rails allowed on sides of body
11. Sunroofs must be closed / covered with sheet metal
12. No holes are allowed in the hood or front fenders and hood should cover entire engine compartment.
13. Holes in firewall and floor should be covered in order to seal off driver from hot fluids or parts.
14. Floor pans and/or firewalls should remain intact between the front strut towers and rear strut towers. Firewalls and floor pans may be patched with plate STEEL for REPAIRS or for fuel cell placement ONLY.
15. Gutting of body above the floor pan is required.
16. Driver and front passenger door window openings along with rear and front window openings must remain open and uncovered. Front windshield visors no more than 12” are allowed. Rear door and/or small rear side windows can be closed or covered.
17. No fins, wings, gurney flaps or lips are allowed anywhere on body. Properly constructed and mounted rear mount spoilers that run from side to side are allowed within reason.
18. Some sheet metal will be allowed. The spirit of this rule is to keep cars remaining as close to stock appearing as possible.
Tires / Wheels / Brakes:
1. Aftermarket racing wheels allowed – 7 inch maximum. Beadlocks are allowed on all four wheels.
2. Street legal DOT tires required. No competition tires, drag radials, mud grip lug tires, racing tires or racing recapped tires allowed. Directional tires are allowed.
3. Tire inner tubes are allowed
4. Tires can be mixed and matched for stagger on all 4 corners
5. Stock-type master cylinders required. No bias adjusters or shut-off valves.
6. Brakes must remain stock-type and operational 4-wheel brakes. Aftermarket pads and rotors are allowed.
Ignition / Fuel / Exhaust:
1. Any air or oil filters (K&N, etc.). Air intake filters must be closed on the end.
2. Intake must be a stock intake. Porting and polishing are allowed. No Skunk 2, etc. - Any racing fuel or pump gas allowed
3. No Nitrous oxide or nitro methane mixing allowed
4. Stock-type fuel injection or stock manufactured carburetor only (Motorcraft, etc...). ONE 0.800" maximum throttle body spacer may be used. Stock-type aftermarket and OEM throttle bodies are allowed. No Holley, Weber or other racing carburetors allowed. Carbureted cars must be stock for engine.
5. No cold air intakes for fuel injections – must be stock type breather system. A flexible rubber or plastic hose may be used in place of the stock air box tube. No smooth metal or smooth plastic tubing allowed. A cone type filter is allowed and may be connected directly to the throttle body or the allowed tubes.
6. Aftermarket radiators allowed and can be braced for support
7. Aftermarket header is allowed.
8. Computer may be chipped and/or tuned. A standalone ECU and aftermarket harness are allowed.
9. Ignition coils must remain OEM however the coil-on-plug kits are allowed.
10. Racing fuel cells are allowed. An approved racing fuel cell must be commercially produced with a plastic or rubber bladder as well as an outer metal enclosure. Cell should be mounted properly as per manufacturers recommendations and it should have a rollover valve or ball.
11. Fuel cells must have both a vertical and horizontal fire wall to separate from driver compartment. Fuel cells are recommended to be placed to the rear of the driver compartment.
12. Fuel lines which run through the cockpit should be fully shielded with a firewall or within metal conduit.
13. The fuel rail may be aftermarket in the interest of safety. A fuel pressure regulator and/or gauge are allowed.
14. Exhaust which runs through the cockpit should be fully shielded from driver with metal
15. Exhaust pipes must not extend out of any body surface more than 1” and pipe must be blunt and free of sharp edges.
Safety:
1. RACING helmet with Snell SA 2010 or FIA 8860-2010 certification or newer is required (no motorcycle or DOTs helmets) (New Snell helmet standard becomes effective at the end of 2025) - Minimum single-layer fire suit required (SA 3.2A specification recommended).
2. Racing shoes (SFI Spec 3.3) are REQUIRED to be worn during competition or on the racing surface.
3. Fire proof gloves are mandatory (SFI 3.3 specification recommended).
4. A 4 or 5-point harness, properly mounted per manufacturers’ specifications, is required. Harness certifications are good for 5 years from date of SFI certification or until marked expiration. Any worn, abraded or torn belts shall be replaced. Harnesses should be mounted to roll cage at all attachment points.
5. A minimum 5 lb. fire extinguisher or on-board fire suppression system is strongly recommended and should be securely mounted within drivers reach.
6. Only commercially produced racing-type seats which are properly mounted per manufacturers’ specifications are allowed. A full containment seat is strongly recommended. Cars equipped with full containment seats will receive a 50 lbs. weight break.
7. A head and neck restraint system (SFI 16.1 compliant) is strongly recommended. Drivers using a head and neck restraint will receive a 50 lbs. weight reduction.
8. Head and Neck Restraint certifications are good for 5 years from date of SFI certification.
9. All glass, plastic and air bags shall be removed
10. Interiors should be free of debris and sharp edges
11. Batteries must be securely attached inside engine compartment or may be relocated inside a securely mounted box. Wet cell batteries that are inside the driver compartment MUST be covered with a non-conductive cover (plastic or rubber).
12. Door intrusion plate on driver’s side door bars strongly recommended.

First of all, on behalf of the entire staff of Mitchell's Motorplex, we would like to thank you for choosing
to race with us. We will do our part to be fair and consistent in our calls and your respect of these is
greatly appreciated. Please take time to read these procedures, as it is your responsibility to know
these. We will cover only the key parts each night in the drivers meeting.
A. DISCLAIMER
The rules and/or regulations set forth herein are designed to provide for the orderly conduct of racing
events and to establish minimum acceptable requirements for such events. These rules shall govern the
condition of all events, and by participating in these events, all participants are deemed to have
complied with these rules. NO EXPRESSED OR IMPLIED WARRANTY OF SAFETY SHALL RESULT FROM
PUBLICATIONS OF OR COMPLIANCE WITH THESE RULES AND/OR REGULATIONS. They are intended as
a guide for the conduct of the sport, the construction of a racecar, and are in no way a guarantee against
injury or death to a participant, spectator, or official.
Mitchell's Motorplex management shall be empowered to permit reasonable and appropriate deviation
from any of the specifications herein or impose any further restrictions that in his/her opinion do not
alter the minimum acceptable requirements. NO EXPRESSED OR IMPLIED WARRANTY OF SAFETY SHALL
RESULT FROM SUCH ALTERATION OF SPECIFICATIONS. Any interpretation or deviation of these rules is
left to the discretion of the officials. Their decision is final.
The events will run under Mitchell's Motorplex rules and all participants acknowledge that they have
received, read and understand all of the rules and regulations associated with the event, and hereby
agree to abide by all official Mitchell's Motorplex decisions and regulations. Any deviation of these rules
and regulations may result in fines or penalties, including disqualification from the event.
B. GENERAL TRACK RULES
1. 2. 3. 4. Mitchell's Motorplex is private property. The management reserves the right to refuse entry to any
individual(s) and/or vehicle(s) onto the property and further reserves the right to eject any
individual(s) and/or vehicle(s) from the premises at any time, if in their discretion, determines
their presence or conduct is not in the best interest of Mitchell's Motorplex.
The management reserves the right to suspend, disqualify, bar, and/or fine (with payment as a
condition of further competition) any participants who, in their discretion, are engaged in
misconduct, and whose presence or conduct is deemed not to be in the best interest of Mitchell's Motorplex. The duration and severity of any such action shall be determined solely by the
management.
Mitchell's Motorplex track officials will act upon any situation not specifically covered by this
rulebook and their decisions shall be final.
The pit area is considered a RESTRICTED AREA. Before entering the pit area, everyone must
properly complete and sign an insurance waiver release form. Entering the pit area without
signing the release form is prohibited and shall be considered trespassing. Persons under the
age of 18 must submit a Parental Consent, Release and Waiver of Liability, Assumption of Risk
Publish Date:
NOTE: Changes from previous version shown in red.5. 6. 7. 8. 9. Mitchell's Motorplex 2025 Track Rules
and Indemnity Agreement/Minor’s Assumption of Risk and Release and waiver of Liability signed
by their parent/or legal guardian. No exceptions.
ATVs/UTVs will be allowed at the facility, with the following limitations:
a. Mitchell's Motorplex had the right to refuse any ATV/RTV at the gate. If it is lifted with mud
tires that we think will tear up our roads or damage our grounds, it will not be let in.
b. All drivers of these vehicles must be 16 years of age and older with a valid driver’s
license. Mitchell's Motorplex has the right to impound the ATV/UTV for the night if
someone underage is found to be driving.
c. No ATV/RTV will be allowed on the racing surface unless approved by officials.
d. No ATV/RTV is allowed to park on the entrance road of the track.
All persons signing into the pit area are expected to conduct themselves in a sportsmanlike
manner on and off the racetrack. As such:
a. Fighting and/or behavior threatening violence will not be tolerated. Involvement is
punishable by up to suspension or being barred from the facility.
b. Illegal drugs, drug paraphernalia or weapons are not permitted on the property.
c. The use of alcoholic beverages is not permitted immediately before or during a
competition event. Any driver suspected of being under the influence of alcohol will be
subject to a breathalyzer test prior to being allowed to race.
d. Penalties for being caught with items listed in section b above OR driver being found to
be under the influence of alcohol prior to racing are as follows:
i. First offense – Immediate expulsion from the facility for the night with no
refund on pit passes or entry fees.
ii. Second offense – Suspension for remainder of current season.
e. All signage on race cars shall be in good taste. Profanity and indecency will not be tolerated.
Cars entering, exiting, and traveling through the pits must travel at a slow, safe rate of speed.
The driver and car owner assume ALL RESPONSIBILITY FOR ACTIONS OF THEIR PIT CREW.
The scoring booth and/or flag stand are not to be entered by anyone other than designated Mitchell's Motorplex officials. In the event of any question regarding scoring decisions, the
questioning driver and/or owner may be invited into the scoring booth or track office upon
completion of the race for an explanation. (NOTE: Please understand that we are human as
well and not infallible. Our race officials/management will be glad to speak with you in a
civilized and respectable manner to address your concerns. Any aggressive, unruly, or
disrespectful behavior will be met in kind by our Security personnel. Offenders will be escorted
Publish Date:
NOTE: Changes from previous version shown in red Mitchell's Motorplex 2025 Track Rules
from the facility and may face disqualification, suspension, or be barred from future events at
the facility.)
10. All drivers in competition are required to be equipped with a fully functional RaceCeiver or
similar brand of one-way unit. You will not be allowed to race without one. It is recommended
that competitors have extra batteries on hand. If you are having an issue with your
RaceCeiver, you must notify a track official prior to entering the racetrack. NOTE: RaceCeivers
are for Race Official to Driver communication only. Any team caught communicating will lose all
points and pay for that event and additional punishments may apply. If any communication
device other than a RaceCeiver is found in the car, you will be disqualified. NO POINTS - NO PAY -
NO EXCEPTIONS.
11. Mandatory Drivers Meetings attendance is required. In most cases, the drivers meeting will be
held prior to hot laps. Any rule, format or schedule changes will be discussed at the drivers
meeting. ALL DRIVERS will be responsible for information discussed at the drivers meeting. The
drivers meeting is not a social gathering. Driver and/or team representative attendance and
attention are mandatory.
12. All drivers must pack the track. If you do not pack the track when called to do so, you will start
at the rear of your heat race unless otherwise cleared by the Race Director/management.
13. Drivers can compete in more than one class per race event with Race Director’s approval. If you
run more than one class, you must purchase a pit pass for each class that you race.
14. Drivers may change cars at any time between qualifying/heats/B‐Main and the start of the Main
Event at the discretion of the Race Director. However, any change will result in the driver
starting in the rear of his/her heat race, B‐Main or Main Event. It is the driver’s responsibility to
notify track officials of any desired change PRIOR to cars being lined up in staging for that race.
15. Any driver hitting another driver’s car under non-racing circumstances, at any time, for any
reason, will be suspended with no pay and no points for a minimum of two race events, and up
to a maximum lifetime suspension.
16. Tow hook/chain is mandatory for the front and rear of all cars. This will speed up the time to get
the track cleared and resume the race.
17. No mirrors will be allowed in any race cars.
18. Time limits (one minute per scheduled lap of event) may be placed upon all events, at the
discretion of the Mitchell's Motorplex officials. Race Director reserves the right to conclude a race
at any time. Race Director reserves the right to shorten or lengthen number of laps scheduled
for heat and/or feature events at any time.
19. DO NOT PULL OFF THE RACETRACK UNDER GREEN FLAG CONDITIONS. At no time shall a car try
to leave the track at the normal track exit (located at the entrance to turn 3) under green flag
conditions. In the event a car must retire from an event early, they are to continue around the
track (if possible) until an official directs them to the infield area.
Once a car leaves the track that car is done for that race. Cars are not allowed to reenter the race track during a race.
Publish Date:
NOTE: Changes from previous version shown in red Mitchell's Motorplex 2025 Track Rules
20. Softening or chemical treating of tires is not allowed in any class at Mitchell'sMotorplex. Solvents
of any kind are not allowed. Treating tires with any components or chemicals which alter the
manufacturer’s baseline settings of the tire are not allowed. WE WILL RANDOMLY TEST FOR
THIS ON OCCASION. For non-sanctioned classes, the penalty will be loss of all money and points
for the night in question, plus a suspension for the next race held at our track. Sanctioned
classes will follow the rules/penalties/fines outlined by their requisite sanctioning body.
C. SAFETY RULES
Safety equipment specifications listed below are listed as a guide and are only a minimum standard.
These minimum standards may not be sufficient to protect a driver from injury or death from some
incidents. It is the responsibility of the driver, car owner, and crew to ensure that the safety equipment
on the car is properly installed, working as intended, and is sufficient to protect the driver from any
incidents that occur. This may include using safety equipment that goes above and beyond the minimum
specifications and recommended equipment listed below.
1. 2. 3. 4. 5. 6. 7. All drivers must wear a certified full‐coverage crash helmet. A helmet certified to Snell SA2010,
SA2015 or SA2020 is REQUIRED to be worn during competition. Motorcycle/DOT helmets are
not allowed.
Complete fire‐resistant suits and shoes are required for all drivers. Top and bottom must both
be worn, if a two-piece design. Any driver not having a complete fire suit and shoes will not be
allowed to compete in any event. Gloves and underwear are not mandatory but are STRONGLY
RECOMMENDED.
The use of a commercially manufactured head and neck restraint device is also STRONGLY
RECOMMENDED. At a minimum, each driver should wear a neck roll/collar or similar device.
Cars will be checked in pre-race inspection for this, as well as while in staging area and on the
racetrack.
All entrants must have a fully charged fire extinguisher in their cars at all times mounted within
reach of driver. An in-car Fire Suppression System is highly recommended.
All weights must be securely mounted inside or on the frame of the car. Must be mounted with
two (2) one-half (1/2) inch bolts (Grade 5 minimum) per fifty (50) pounds of ballast. May not
have more than twenty-five (25) pounds mounted on a single half-inch (1/2) bolt. All weights
must be painted white with car number clearly marked on each piece. Mounting of weight
within the driver’s compartment is STRONGLY DISCOURAGED.
All rear-wheel-drive cars must have a drive shaft loop (aka a drive line “sling”) and all drive
shafts must be painted white.
A safety net on the window is required, and a minimum of three (3) bars in the front of the
steering wheel/driver in the windshield area are recommended. All safety nets must have a top
quick release.
Publish Date:
NOTE: Changes from previous version shown in red. Mitchell's Motorplex 2025 Track Rules
8. Roll cage required in all race cars. Shall be minimum four-point cage, minimum of three door
bars on driver’s side, and at least two door bars on passenger side. 1/8 steel door plate on
driver’s side door is HIGHLY RECOMMENDED.
9. Factory-manufactured racing seats are required and must be acceptable to Technical Inspector.
Full-containment racing seats are STRONGLY RECOMMENDED FOR 2024. Beginning in 2025, ALL
RACE CARS WILL BE REQUIRED TO HAVE A FULL-CONTAINMENT RACING SEAT. Homemade
aluminum, plastic or fiberglass seats are not allowed. All seats must be properly mounted &
secured per Technical Director’s recommendations. The use of Grade five (5) or better hardware
is also required to attach the seat to the chassis. Bolts should be a minimum of 3/8 inches thick.
10. Safety racing belt and shoulder harness is mandatory on all cars. The use of a five (5), six (6) or
seven (7) point driver restraint system is REQUIRED, no exceptions. No driver restraint systems
shall be in excess of three (3) years of age past the date of manufacture. All mounting points of
the racing harness MUST be mounted properly in accordance with the manufacturer’s
instructions, and securely mounted to the chassis with the use of Grade five (5) or better
hardware.
11. Gas tanks or fuel cells may be relocated for safety in all classes. Fuel cells are recommended in
all classes.
12. There must be a marked electrical kill switch within reach of driver.
13. ONLY track officials and emergency crew are allowed on the track during yellow or red flag
periods. This is for your safety only. Only authorized personnel are allowed on the track or in the
infield.
D. RACE PROCEDURES
1. Pill Draw:
a. b. a. Unless otherwise announced, the pill draw (for heat race line-up purposes and/or time
trial order) will take place in the pit area at driver registration. Any team member can
draw the pill.
On ‘regular’ events, the pill draw will end promptly one-half hour before the scheduled
hot lap time. Cars arriving after that point will be lined up ‘scratch’ in a heat race. In the
event that time trials are used, the time trial order will be derived from the pill draw.
2. Staging Area / Lineup:
It will be the team’s responsibility to be aware of the lineup and event order. The
lineups will all be posted on the board in the pits (next to staging lane behind turn 3)
well in advance of your race and you need to be lined up two races in advance.
If not lined up by the time your race starts going onto the track, you will start at the
rear. If you have to be push started in the staging area or pushed onto the track, you will
fall to the rear. You must enter the track under your own power. If you have to be push
started once you are on the racetrack, you will be allowed to keep your position.
Publish Date:
NOTE: Changes from previous version shown in red.
b. 3. c. d. Mitchell's Motorplex 2025 Track Rules
If not on the track by the start of the race, driver will not be allowed onto the track
unless approved by the Race Director.
If a driver misses his/her heat, they will start at the end of another heat if approved by
the Race Director. If driver misses all heats, they will start at the rear of a consolation
race/Bmain if approved by the Race Director. If a car misses the call for their race for
any reason, the line-up will be adjusted by moving the remainder of that row up one
spot within their row. No crisscrossing re-lineups will be done once cars roll onto the
track.
Work Area / Hot Pits:
a. b. c. d. This area is located in the infield behind the back straightaway wall. Please have your
equipment/parts in the work area if you plan on doing the necessary repairs to your car.
There is a cool-down station / water hose in the infield near the work area, as well as
one in the pits behind turns 3 and 4.
If you go to the infield, you will be allowed back onto the track only under yellow flag
conditions or if the field is entering turn 1 after receiving the green flag.
You will be allowed two courtesy laps once you enter the work area and after that, the
race will resume if the lineups are complete.
Only 2 persons allowed in hot pit per car.
e. 4. Flag Rules:
a. Standard flagging procedures will be used for each Mitchell's Motorplex event.
i. ii. iii. iv. v. vi. Green Flag - The entire track is open for racing. Passing will not be permitted
before the green is displayed at the designated point.
Yellow Flag - All cars must come to a parade lap speed as soon as safely possible
and fall into a single file formation. Absolutely no passing is permitted under the
yellow flag and no racing to the start/finish line will be permitted.
Red Flag - When a red flag is displayed, all cars must come to a complete stop as
soon as safely possible.
Black Flag - A car given this flag must pull into the infield immediately for
consultation. The car will not be scored from the point that the black flag is
displayed. If, after the car is inspected and deemed able to return to the race by
track officials, the car may return to the track. If a car is stopped and found to
be safe and/or not at fault, the car will retain the same position as it was
running (only if black flagged under yellow flag conditions).
Blue/Yellow Flag “Move-over” - A “Move Over” flag will be utilized. Hold your
line. The leaders are approaching. Do not race the other lapped cars or lead cars
at this time.
White Flag - One lap remains in the race. When the white flag is displayed, cars
will race back to the checkered flag. Only exception will be if the track is
blocked/unsafe, in which case a red flag will be thrown.
Publish Date:
NOTE: Changes from previous version shown in red. Mitchell's Motorplex 2025 Track Rules
vii. Checkered Flag - The race is officially ended, and all cars must pass underneath
it to be scored on the last lap. A race is not completed until the checkered flag is
displayed.
5. Initial Starts:
a. b. c. d. e. The front two cars are to set a nice/even pace down the backstretch. Everyone is to stay
side by side and nose to tail. There are two cones on edge of infield, the first being
placed in the Middle of turns 3 & 4 and the other towards the exit of 4. This is known as
the “Acceleration Zone.” The pole sitter has the right to fire at any time while in this
zone. If the pole sitter does not fire by the second cone/wall marking, the flagman will
automatically start the race.
Brake checking on a start or restart will not be tolerated. If you change your pace
coming to the green flag on a start or restart and cause damage to another car, you will
be subject to disqualification from that race with no warning.
Any attempt by the pole sitter or outside pole sitter to start the race outside of/prior to
the “Acceleration Zone” will be considered a jump-start.
Any car(s) that pulls out of line and passes another car within the “Acceleration Zone”
will be considered a jump-start.
Any car involved in a jump-start will be penalized two positions/one row on the next
restart or at the finish, whichever comes first. THERE WILL BE NO WARNINGS ON JUMP-
STARTS. IF YOU ARE DEEMED TO HAVE JUMPED, YOU WILL BE MOVED BACK TWO (2)
f. g. h. 6. Restarts:
POSITIONS. We will not throw the yellow flag and immediately go to a restart in the
event of a jump-start. The offending car will be notified on the RaceCeiver, and the
penalty enforced either on the next restart or at the finish/payout.
Once the green flag drops, the race is officially underway. On the original start and
before one (1) complete lap is scored, if only one car is involved in a caution and stops
on the track, that car will restart from the tail. If more than one (1) car is involved in a
caution before one (1) lap is scored, all cars involved in the caution that came to a stop
will receive their original starting positions, provided there are no penalties to be
assessed. If penalties are assessed, penalized car(s) restarts from the rear.
Laps will count when the leader plus three (3) cars cross the finish line.
Race Director reserves the right to call for a complete restart at his/her discretion.
a. b. When the yellow comes out, drivers are to run single file at a slow pace. We will use
Delaware-style double-file restarts - defined as leader alone on front row with
remainder of the field double filed behind the leader. Once race officials have the lineup
correct, the leader will be motioned out front alone, then the second-place position will
get his/her choice of inside or outside row. Second place car must make decision clear.
Third place is to fall in opposite position. Fourth place will always be inside row and the
field should fall into place accordingly.
Anytime a race has three (3) or less laps remaining, or if track conditions do not allow,
the race will restart in a single file formation.
Publish Date:
NOTE: Changes from previous version shown in red. a. b. c. Mitchell's Motorplex 2025 Track Rules
On restarts, the leader may fire anywhere within the aforementioned “Acceleration
Zone” and the race will be considered underway. Jump-start rules identified in sections
5.c. through 5.e. above will apply.
7. Cautions / Red Flags:
Drivers are allowed one (1) caution per race. A second charged caution will result in a
black flag and the driver will be scored accordingly.
The car(s) deemed at fault will be put to the rear or black-flagged pending the Race
Director’s judgment.
There will be NO racing back to the caution except on the final lap once the leader has
been shown the white flag. The field will then race back to the checkered flag. The
flagman will turn the yellow and green lights on to indicate to the field they are racing
back to the checkered flag.
In the event of an unsafe condition or a completely blocked track on the final lap, the
red flag/light will be displayed, and the field will be realigned as it was on the last
completed lap for a green, white, checkered finish.
Under red flag conditions, all race cars must come to a complete stop on the racetrack.
In the event of either a Caution or a Red Flag, after one (1) lap has been scored, any car
that goes into the infield / hot pit area / main pits will rejoin the field at the rear.
You may enter the infield at any entrance. YOU MAY NOT RE-ENTER THE TRACK FROM
THE PITS DURING GREEN FLAG CONDITIONS. You must wait until the next caution to re-
d. e. f. g. h. i. j. k. l. m. n. enter the track and only when a track official directs you to do so. During “one to go”
caution conditions, cars must re-enter behind the field.
Field line up will revert to last completed and scored lap order after a red or yellow flag.
Lapped cars will be placed at the tail end of the lineup.
A competitor may continue with a flat tire (left front only) or broken suspension part,
unless an official feels they are putting themselves or others in a dangerous or
potentially dangerous position (door panels or bumpers falling off, broken a-frames,
etc.). For safety reasons, they must be able to keep up with the field.
During a yellow flag caution, a car may stop on the track for track officials to check car
damage. If minor help is needed, the track workers will render that help. No one from
the driver’s crew is allowed on the racetrack. If ANY team helper/ crew chief, etc. is
caught on the racing surface, the driver of the car is responsible and may be
disqualified.
Two (2) courtesy laps will be given in the feature race only for changing flat tires or
making repairs in the work area/hot pit. The courtesy laps will begin once the lineup is
set on the track. The car will rejoin the field at the tail.
All drivers are to remain in their cars while on the track, unless granted permission by
an official (over RaceCeiver or otherwise). If you exit your car without due cause, you
will be disqualified from that race.
During a red flag, NO ONE in the current race is allowed to work on the car (on or off the
track). Violators will not be allowed to continue.
Publish Date: December 5, 2022
NOTE: Changes from previous version shown in red. 8. Mitchell's Motorplex 2025 Track Rules
Race Director retains the right to disallow a competitor to continue if it is felt the
caution was intentional. This includes, but is not limited, to rough driving, sitting in the
corners, etc. Car(s) will retain their position for debris and safety yellows.
Post-Race Procedure for Exiting Racetrack:
a. After the checkered flag is thrown on ANY race, all cars must go the infield at the infield
entrance located at the exit of turn 4.
Cars that must go to tech will be called to the scales on the RaceCeiver.
Cars will line up on the infield exit road (facing the track exit in turn 3) and stop there.
Cars are not to leave this area until waved off across the racing surface by a track
official.
Any car not leaving the racetrack in this manner will be disqualified from that individual
race and receive no pay or points for that event. For example, if you violate this
procedure after a heat race, you will be disqualified from that heat and be forced to
start on the rear of the feature. If you violate this procedure following a feature race,
you will be disqualified from that feature race.
b. c. d. e. E. TECH / PROTEST PROCEDURES
1. 2. 3. 4. 5. 6. You must report directly to the tech area after the completion of your race as you are instructed
to do so. The scales will be located in the infield. Top five (5) cars are typically required to
report to the scales/tech area after each race. Any changes in this number will be announced
either at the drivers meeting or over the RaceCeiver following conclusion of the race. Failure to
report to the tech area as instructed will result in disqualification for that event. Only the driver
and one other pit crew member or car owner are allowed in the tech area.
Mitchell's Motorplex scales are the official scales for the event unless otherwise specified at the
drivers meeting. All competing teams have the option to come to the infield and weigh/scale
their car at any time.
NO equipment will be considered approved by reason of having passed through previous or pre-
race inspection unobserved.
Track officials reserve the right to tech, spot check, or examine race cars at any time. Failure to
allow this will result in disqualification without refund of money.
Track officials reserve the right to accept or not accept protests at their discretion.
Technical protests will be made after the feature event only. Only a participant in the said race
may file a technical protest. All protests must be filed immediately after the event finish. Protest
must be filed in the infield and required cash for protest presented before car leaves and to goes
to pit area. Once the protesting car leaves perimeter of track, they are ineligible to file protest.
Protest must be made in writing with SPECIFIC protest issues described.
Publish Date:
NOTE: Changes from previous version shown in red. Mitchell's Motorplex 2025 Track Rules
7. Failure or refusal to tear down will result in immediate disqualification and forfeiture of all prize
money, awards, and points for that event.
8. Only cars that finish on the lead lap and in the top 5 are allowed to protest. No spite protests.
Drivers may only protest cars that finish in FRONT of them. No reverse protests allowed.
9. Drivers are allowed one (1) attempted and/or executed technical protest per year.
10. Visual protest (for non-engine items) must be made in writing with SPECIFIC protest issues
described. Any visual protest is $50 cash on EACH item that is a visual protest. ONLY THE TECH
OFFICIAL, THE PERSON BEING PROTESTED, AND THE ONE MAKING THE PROTEST ARE ALLOWED
TO EXAMINE THE PROTESTED ITEM(S). All visual protest fees go to the racetrack.
11. For engine protests, each separate technical protest must be accompanied by a $500 cash
protest fee for the top of the engine (heads, carburetor, bore and stroke, etc.) and/or a $500
cash fee for the bottom of the engine (rods, crankshaft, etc.) $1200 cash protest fee for
complete tear down. All technical protests accompanied by $500.00 cash will be disbursed by
$400.00 going to the protest winner and $100 to the track. All technical protests accompanied
by $1200 cash will be disbursed by $1000 to the protest winner and $200 to the track. Track’s
portion of the protest fee will go to the speedway, regardless of the protest outcome. The only
individuals allowed to examine engine or parts protested are the driver being protested, the
driver protesting, and the Technical Inspector.
12. NO ITEM MAY BE EXAMINED OTHER THAN WHAT HAS BEEN SPECIFICALLY IDENTIFIED IN
WRITING AS BEING PROTESTED.
13. The Technical Inspector’s decision is final.
We would like to thank you once again for choosing to race at Mitchell's Motorplex. We wish you the best
of luck and a pleasant experience. It is our goal to provide a fun/safe environment, put on a great show
for the fans, and make each night a special event. Best of luck and we look forward to seeing you again
We use cookies to analyze website traffic and optimize your website experience. By accepting our use of cookies, your data will be aggregated with all other user data.
